Grundfos 91129789 - CRT 16-3 A-P-A-E-AUUE | Multistage | Centrifugal | Vertical | Inline

GRUNDFOSSKU: 91129789

Price:
Sale price$31,350.00
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

CRT 16-3 A-P-A-E-AUUE Vertical, multistage centrifugal pump with inlet and outlet ports on same the level (inline). Pump materials in contact with the liquid are in titanium. The pump is fitted with a mechanical shaft seal, type unbalanced O-ring seal. Power transmission is via a rigid split coupling. Pipe connection is via PJE (Victaulic®) couplings. The pump is fitted with a 1-phase, fan-cooled asynchronous motor.

EAN 5700398951285
Applications Industrial applications
Approvals CE
Built-in motor protection NONE
Code for rubber E
Connect code P
Connection PJE 2
Cooling TEFC
Curve tolerance ISO9906:2012 3B
Density 62.29 lb/ft³
Eta 1/1 0.82
Flange size for motor 213TC
Frequency 60 HZ
Frequency converter NONE
Gross weight 166.0 lb
Head max 205.1 ft
Housing Titanium
Impeller Titanium
Impellers 3
Liquid max temp 120°C
Liquid temperature range -4 .. 248 °F
Low NPSH N
Material code A
Material Pricing Group 6
Max pressure at stated temp 363 psi / 250 °F
Maximum ambient temperature 104 °F
Maximum operating pressure 362.59 psi
Maximum permissible operating pressure 25bar
Model A
Motor 213TC
Motor efficiency at full load 1 0.82
Motor protec NONE
Motor standard NEMA
Motor type BALDOR
n rpm 3450rpm
Net weight 149.0 lb
Number of poles 2
P2 HP 7.5 HP
P2 kW 5.5kW
Phase 1
Pipe connection PJE 2
Primary shaft seal AUUE
Product family CRT 16
Pump housing Titanium
Pump version A
Pumped liquid Water
Rated flow 79.3 US gpm
Rated flow 2 79.3 US gpm
Rated head 170.9 ft
Rated head 2 170.9 ft
Rated power - P2 7.5 HP
Rated speed 3450 rpm
Rated voltage 1 x 208-230 V
Real Time Delivery date to be confirmed on Sales Order Update with real time availability and Net price
Rubber E
Selected liquid temperature 68 °F
Service factor 1.15
Shaft seal AUUE
Stages 3
Standard NEMA
Type BALDOR
Version A

Motor Curves

Dimensional Drawing
