Model CONTROL · SGV Grinder Pumps · Barnes

1.25″ Vertical Bolt-on Flange, 2″ NPT Vertical DischargeUp to 106 gpmUp to 160 ft Head3 – 7.5 HP Range

The Barnes CONTROL, 200 (1 and 3 phase), 240 (1 and 3 phase), 480, 600 barnes control panel nema 4 enclosure for simplex versatrol standard and sgv grinder panels (64682). Barnes SGV Grinder Pumps provide broad design flexibility with a choice of basin configurations. Designed for reduction of domestic, commercial, institutional and light industrial sewage to a finely ground slurry. Series capacity up to 106 gpm at 160 ft head.

HP Range

3 – 7.5

Max Flow

106 gpm

Max Head

160 ft

Discharge

1.25″ Vertical Bolt-on Flange, 2″ NPT Vertical

Speed

3450

Voltage

200 (1 and 3 phase), 240 (1 and 3 phase), 480, 600

Grinder Technology

Stainless steel cutter macerates solids for low-pressure sewer service

Crane Pumps & Systems

A Crane Co. company — 165+ years of pump engineering. Barnes, Burks, Deming, and Weinman under one roof in Piqua, Ohio

Wide HP Range

3 – 7.5 HP available

Expert Support

Technical sizing and compatibility help — call (781) 281-8905 or chat

Why This Product

Grinder Mechanism — Macerates Solids Before Pumping

Stainless steel cutting ring and impeller macerate waste, wipes, and non-dispersible materials to a fine slurry before pumping — required for low-pressure sewer systems where raw sewage would block small-diameter discharge piping.

Low-Pressure Sewer Compatible

Designed to force slurry through small-diameter discharge piping uphill and over long horizontal runs — the correct pump type for below-grade plumbing where gravity connection to the municipal sewer is not possible.

Stainless Steel Cutting Components — Long Service Life

Stainless steel cutter components maintain sharp edges over extended service and resist corrosion from the sewage environment. Self-cleaning cutting action prevents material buildup on cutter surfaces.

Automatic Float Control

Float switch provides fully automatic operation — activates on rising basin level and deactivates when the basin empties. High-level alarm float provides early warning before overflow conditions develop.

Pre-Assembled Systems Available

Complete pre-assembled grinder packages available with basin, guide rails, and controls — one shipment, one installation, no component compatibility concerns.

Crane Pumps & Systems — SGV Industry Standard

Barnes and Deming grinder pumps are manufactured by Crane Pumps & Systems — one of the most recognized names in residential and municipal grinder pump applications.

Technical Specifications

Model Number	nan
Series	SGV Grinder Pumps
Brand	Barnes
Horsepower	3 – 7.5
Voltage	200 (1 and 3 phase), 240 (1 and 3 phase), 480, 600
Series HP Range	3 – 7.5
Max Flow Rate	106 gpm
Max Head	160 ft
Discharge Size	1.25″ Vertical Bolt-on Flange, 2″ NPT Vertical
Speed	3450

Key Features

UL & CSA Listed

Cast Iron Construction

Stainless Steel Hardware

Quick Connect Style Cords

Class F Insulation

Capacitor Start / Capacitor Run

Single Phase Design

Oil Filled Motor

Thermal Overload Sensors

Available Options

Seal Material

Impeller Trims

Cord Length

Moisture Sensors

Moveable Fitting

Breakaway Fittings

Leg Kit

Typical Applications

Wastewater for Domestic

Commercial

Institutional and Light Industrial

Important Notices

Fluid compatibility	For use with liquids compatible with pump component materials. Verify chemical, temperature, and pressure compatibility before use.
Electrical	Requires a properly sized grounded branch circuit and motor starter with correctly rated thermal overload protection.
Operating limits	Do not exceed series pressure, temperature, and speed ratings. Operation outside rated limits causes premature seal and bearing failure.
Service	Disconnect and lockout/tagout power before any service. Allow pump to cool before handling after operation.

Available Documentation

✓ Product Specification Sheet — SGV Grinder Pumps

✓ Installation, Operation & Maintenance Manual (IOM)

✓ Repair Parts Manual

Need the spec sheet, IOM, or parts list? Contact PumpStop and we'll send it over.

Before You OrderConfirm HP, voltage, phase, and enclosure type are correct for your installation. All models in the SGV Grinder Pumps share casing dimensions and spare parts — motor configuration is the only difference between models. For sizing guidance, chat or call (781) 281-8905.
