Barnes 119331 - Pump, EP72X, 230/1, 20', Ma

BarnesSKU: 119331

Price:
Sale price$653.40
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Crane Pumps & Systems — Barnes Brand · Piqua, Ohio · Est. 1856
Model PUMP · SP EP Series · Barnes
1.5″ DischargeUp to 80 gpmUp to 32 ft Head0.33 (SP Series Only), 0.50, 0.75 HP Range

The Barnes PUMP, 120V (1 phase) pump, ep72x, 230/1, 20', ma. Barnes sump pumps are robustly designed for long operational life, quiet operation, and dependable service. They are ideal for dirty water applications with minimal solids, and are available with or without integral level controls and in a variety of construct Series capacity up to 80 gpm at 32 ft head.

HP Range
0.33 (SP Series Only), 0.50, 0.75
Max Flow
80 gpm
Max Head
32 ft
Discharge
1.5″
Speed
3450
Voltage
120V (1 phase)
Crane Pumps Engineering
Barnes — manufactured by Crane Pumps & Systems, Piqua, Ohio since 1856
Crane Pumps & Systems
A Crane Co. company — 165+ years of pump engineering. Barnes, Burks, Deming, and Weinman under one roof in Piqua, Ohio
Wide HP Range
0.33 (SP Series Only), 0.50, 0.75 HP available
Expert Support
Technical sizing and compatibility help — call (781) 281-8905 or chat
Why This Product

Crane Pumps & Systems Engineering

Barnes, Burks, Deming, and Weinman pumps are manufactured by Crane Pumps & Systems in Piqua, Ohio — a Crane Co. company with 165+ years of pump engineering for commercial, industrial, and municipal applications.

Wide Performance Range

Multiple HP, voltage, and construction configurations cover your specific duty point. All models in the series share casing dimensions and spare parts — simplifying stocking and service.

Multiple Construction Options

Bronze fitted, all-bronze, all-iron, and specialty alloy configurations with multiple seal material options. Specify the combination matched to your fluid chemistry and service conditions.

Back Pull-Out Serviceability

Back pull-out pump design allows impeller, seal, and wear ring service without disconnecting suction or discharge piping — reducing field service time and cost on installed pumps.

NEMA-Frame Motors

Standard NEMA motor frame allows direct field motor replacement from any supplier — no custom parts, no factory service required when only the motor has failed.

National Service Network

Supported by a national network of authorized distributors and service centers with genuine Crane Pumps spare parts stocked for same-day or next-day availability.

Technical Specifications
Model Number 119331
Series SP EP Series
Brand Barnes
Horsepower 0.33 (SP Series Only), 0.50, 0.75
Voltage 120V (1 phase)
Series HP Range 0.33 (SP Series Only), 0.50, 0.75
Max Flow Rate 80 gpm
Max Head 32 ft
Discharge Size 1.5″
Speed 3450
Key Features
Permanent Split Capacitor Motor
Oil Lubricated Ball Bearings
Top Suction Volute on Expel Series
Single Piece Motor Housing and Volute on SP/EP Series
Cast Iron Vortex Impeller on SP/EP Series
GFCI Compatible
Available Options
Laundry Tray Package
Manual or Automatic pumps
Integral Level Control
Typical Applications
Plumbing
Residential Sumps
Wet Bars
Water Softeners
Important Notices
Fluid compatibility For use with liquids compatible with pump component materials. Verify chemical, temperature, and pressure compatibility before use.
Electrical Requires a properly sized grounded branch circuit and motor starter with correctly rated thermal overload protection.
Operating limits Do not exceed series pressure, temperature, and speed ratings. Operation outside rated limits causes premature seal and bearing failure.
Service Disconnect and lockout/tagout power before any service. Allow pump to cool before handling after operation.
Available Documentation
✓ Product Specification Sheet — SP EP Series
✓ Installation, Operation & Maintenance Manual (IOM)
✓ Repair Parts Manual
Need the spec sheet, IOM, or parts list? Contact PumpStop and we'll send it over.
Before You OrderConfirm HP, voltage, phase, and enclosure type are correct for your installation. All models in the SP EP Series share casing dimensions and spare parts — motor configuration is the only difference between models. For sizing guidance, chat or call (781) 281-8905.
Supplier Part Number 119331
