Barnes 134678 - Pump, BT50

This item ships free!
BarnesSKU: 134678

Price:
Sale price$487.80
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Crane Pumps & Systems — Barnes Brand · Piqua, Ohio · Est. 1856
Model PUMP · Transfer Pump Series · Barnes
0.75″ G.H.T Male, Vertical DischargeUp to 21 gpmUp to 127 ft Head0.08, 0.5 HP Range

The Barnes PUMP, 120 (1 phase) pump, bt50. Barnes Transfer pumps are designed to handle a wide variety of pumping applications such as draining water heaters, charging polyglycol lines for radiant heating, pressure boosting, draining pool covers and dewatering flooded basements. Barnes Transfer pumps a Series capacity up to 21 gpm at 127 ft head.

HP Range
0.08, 0.5
Max Flow
21 gpm
Max Head
127 ft
Discharge
0.75″ G.H.T Male, Vertical
Speed
3450
Voltage
120 (1 phase)
Crane Pumps Engineering
Barnes — manufactured by Crane Pumps & Systems, Piqua, Ohio since 1856
Crane Pumps & Systems
A Crane Co. company — 165+ years of pump engineering. Barnes, Burks, Deming, and Weinman under one roof in Piqua, Ohio
Wide HP Range
0.08, 0.5 HP available
Expert Support
Technical sizing and compatibility help — call (781) 281-8905 or chat
Why This Product

Crane Pumps & Systems Engineering

Barnes, Burks, Deming, and Weinman pumps are manufactured by Crane Pumps & Systems in Piqua, Ohio — a Crane Co. company with 165+ years of pump engineering for commercial, industrial, and municipal applications.

Wide Performance Range

Multiple HP, voltage, and construction configurations cover your specific duty point. All models in the series share casing dimensions and spare parts — simplifying stocking and service.

Multiple Construction Options

Bronze fitted, all-bronze, all-iron, and specialty alloy configurations with multiple seal material options. Specify the combination matched to your fluid chemistry and service conditions.

Back Pull-Out Serviceability

Back pull-out pump design allows impeller, seal, and wear ring service without disconnecting suction or discharge piping — reducing field service time and cost on installed pumps.

NEMA-Frame Motors

Standard NEMA motor frame allows direct field motor replacement from any supplier — no custom parts, no factory service required when only the motor has failed.

National Service Network

Supported by a national network of authorized distributors and service centers with genuine Crane Pumps spare parts stocked for same-day or next-day availability.

Technical Specifications
Model Number 134678
Series Transfer Pump Series
Brand Barnes
Horsepower 0.08, 0.5
Voltage 120 (1 phase)
Series HP Range 0.08, 0.5
Max Flow Rate 21 gpm
Max Head 127 ft
Discharge Size 0.75″ G.H.T Male, Vertical
Speed 3450
Key Features
Molded handles
Suction Strainer Included
BT12 includes a spare impeller, gasket, and hose
BT50 includes fittings, strainer, and spare brushes
3/4″ male outlet for use with standard garden hose
Pumps are durable thermoplastic for decreased weight
Motors utilize permanently greased bearings for quiet operation
Typical Applications
Draining water heaters
Charging polyglycol lines for radiant heating
Pressure boosting
Draining pool covers dewatering flooded basements
Important Notices
Fluid compatibility For use with liquids compatible with pump component materials. Verify chemical, temperature, and pressure compatibility before use.
Electrical Requires a properly sized grounded branch circuit and motor starter with correctly rated thermal overload protection.
Operating limits Do not exceed series pressure, temperature, and speed ratings. Operation outside rated limits causes premature seal and bearing failure.
Service Disconnect and lockout/tagout power before any service. Allow pump to cool before handling after operation.
Available Documentation
✓ Product Specification Sheet — Transfer Pump Series
✓ Installation, Operation & Maintenance Manual (IOM)
✓ Repair Parts Manual
Need the spec sheet, IOM, or parts list? Contact PumpStop and we'll send it over.
Before You OrderConfirm HP, voltage, phase, and enclosure type are correct for your installation. All models in the Transfer Pump Series share casing dimensions and spare parts — motor configuration is the only difference between models. For sizing guidance, chat or call (781) 281-8905.
Supplier Part Number 134678
