Name: Barnes 110952 - Pump, 3SF1524HD, 1.5 HP 1.5 HP
Brand: Barnes
SKU: 110952
Price: 5244.3 USD
Availability: InStock

Image shown may not be actual product

Crane Pumps & Systems — Barnes Brand · Piqua, Ohio · Est. 1856

Model PUMP · Air-Filled SyFlo Pump · Barnes

1.5 HP3″-4″ DischargeUp to 1050 GPMUp to 160 ft Head3-15 HP Range

The Barnes PUMP is a 1.5 HP, 208/230 (1 and 3 phase), 460, 575 pump, 3sf1524hd, 1.5 hp 1.5 hp. Introducing SyFlo, the latest high-efficiency solids handling solution designed for superior performance and reliability. Engineered with innovative scroll and vortex impellers, SyFlo delivers exceptional clog resistance and hydraulic efficiency, reducing ener Series capacity up to 1050 GPM at 160 ft head.

HP Range

3-15

Max Flow

1050 GPM

Max Head

160 ft

Discharge

3″-4″

Speed

1750 & 3450

Voltage

208/230 (1 and 3 phase), 460, 575

Crane Pumps Engineering

Barnes — manufactured by Crane Pumps & Systems, Piqua, Ohio since 1856

Crane Pumps & Systems

A Crane Co. company — 165+ years of pump engineering. Barnes, Burks, Deming, and Weinman under one roof in Piqua, Ohio

Wide HP Range

3-15 HP available

Expert Support

Technical sizing and compatibility help — call (781) 281-8905 or chat

Why This Product

Crane Pumps & Systems Engineering

Barnes, Burks, Deming, and Weinman pumps are manufactured by Crane Pumps & Systems in Piqua, Ohio — a Crane Co. company with 165+ years of pump engineering for commercial, industrial, and municipal applications.

Wide Performance Range

Multiple HP, voltage, and construction configurations cover your specific duty point. All models in the series share casing dimensions and spare parts — simplifying stocking and service.

Multiple Construction Options

Bronze fitted, all-bronze, all-iron, and specialty alloy configurations with multiple seal material options. Specify the combination matched to your fluid chemistry and service conditions.

Back Pull-Out Serviceability

Back pull-out pump design allows impeller, seal, and wear ring service without disconnecting suction or discharge piping — reducing field service time and cost on installed pumps.

NEMA-Frame Motors

Standard NEMA motor frame allows direct field motor replacement from any supplier — no custom parts, no factory service required when only the motor has failed.

National Service Network

Supported by a national network of authorized distributors and service centers with genuine Crane Pumps spare parts stocked for same-day or next-day availability.

Technical Specifications

Model Number	110952
Series	Air-Filled SyFlo Pump
Brand	Barnes
Horsepower	1.5 HP
Voltage	208/230 (1 and 3 phase), 460, 575
Series HP Range	3-15
Max Flow Rate	1050 GPM
Max Head	160 ft
Discharge Size	3″-4″
Speed	1750 & 3450

Key Features

Slotted ANSI/ISO Flange Discharge (NPT Option on 3” 3HP Only)

IE3 Rated Air Filled Motors, 3450 & 1750RPM

Submersible Motor Suitable for Continuous Operation at Partial Submergence

Minimum 3” Solids Handling on Most Models

Standard & Explosion Proof Construction

VFD Compatible

Tandem Seal Design – C/SC Upper, SC/SC Lower

30’ Quick Disconnect Cord Standard, with 50’, 75’ & 100’ Options

Powder Coat Epoxy Paint in Deming Green

5 Year Full Warranty from Shipment

Compatible with Existing BAF’s

Available Options

White Iron (25% Chrome) Impeller

Additional Cord Lengths

Guide Rail Systems

Leg Kit for Free Standing Applications

Typical Applications

Municipal Wastewater

Raw Sewage

Abrasive Wastewater Applications

Wastewater Treatment Plants

Collection Systems

Storm Water

Important Notices

Fluid compatibility	For use with liquids compatible with pump component materials. Verify chemical, temperature, and pressure compatibility before use.
Electrical	Requires a properly sized grounded branch circuit and motor starter with correctly rated thermal overload protection.
Operating limits	Do not exceed series pressure, temperature, and speed ratings. Operation outside rated limits causes premature seal and bearing failure.
Service	Disconnect and lockout/tagout power before any service. Allow pump to cool before handling after operation.

Available Documentation

✓ Product Specification Sheet — Air-Filled SyFlo Pump

✓ Installation, Operation & Maintenance Manual (IOM)

✓ Repair Parts Manual

✓ Product Catalog — Value Sheet | Brochure | Sales Sheet

Need the spec sheet, IOM, or parts list? Contact PumpStop and we'll send it over.

Before You OrderConfirm HP, voltage, phase, and enclosure type are correct for your installation. All models in the Air-Filled SyFlo Pump share casing dimensions and spare parts — motor configuration is the only difference between models. For sizing guidance, chat or call (781) 281-8905.
