Barnes 145027 - Pump, ZOGP2072L

This item ships free!
BarnesSKU: 145027

Price:
Sale price$3,813.30
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Crane Pumps & Systems — Barnes Brand · Piqua, Ohio · Est. 1856
Model PUMP · EcoTRAN Low Pressure Sewer System · Barnes
1.25″ DischargeUp to 28 gpmUp to 200 ft Head2 HP Range

The Barnes PUMP pump, zogp2072l. Barnes Pressure Sewer System offers a solution to the residential market for new or existing sewer needs. The EcoTRAN™ Grinder Pump System preserves groundwater ecology by collecting and grinding residential sewage in an enclosed underground basin system and t Series capacity up to 28 gpm at 200 ft head.

HP Range
2
Max Flow
28 gpm
Max Head
200 ft
Discharge
1.25″
Speed
3450
Crane Pumps Engineering
Barnes — manufactured by Crane Pumps & Systems, Piqua, Ohio since 1856
Crane Pumps & Systems
A Crane Co. company — 165+ years of pump engineering. Barnes, Burks, Deming, and Weinman under one roof in Piqua, Ohio
Wide HP Range
2 HP available
Expert Support
Technical sizing and compatibility help — call (781) 281-8905 or chat
Why This Product

Crane Pumps & Systems Engineering

Barnes, Burks, Deming, and Weinman pumps are manufactured by Crane Pumps & Systems in Piqua, Ohio — a Crane Co. company with 165+ years of pump engineering for commercial, industrial, and municipal applications.

Wide Performance Range

Multiple HP, voltage, and construction configurations cover your specific duty point. All models in the series share casing dimensions and spare parts — simplifying stocking and service.

Multiple Construction Options

Bronze fitted, all-bronze, all-iron, and specialty alloy configurations with multiple seal material options. Specify the combination matched to your fluid chemistry and service conditions.

Back Pull-Out Serviceability

Back pull-out pump design allows impeller, seal, and wear ring service without disconnecting suction or discharge piping — reducing field service time and cost on installed pumps.

NEMA-Frame Motors

Standard NEMA motor frame allows direct field motor replacement from any supplier — no custom parts, no factory service required when only the motor has failed.

National Service Network

Supported by a national network of authorized distributors and service centers with genuine Crane Pumps spare parts stocked for same-day or next-day availability.

Technical Specifications
Model Number 145027
Series EcoTRAN Low Pressure Sewer System
Brand Barnes
Horsepower 2
Series HP Range 2
Max Flow Rate 28 gpm
Max Head 200 ft
Discharge Size 1.25″
Speed 3450
Key Features
Field Adjustable Riser and Three Inlet Port Positions Allow Piping Flexibility and Ease of Installation
Installation Via Directional Boring Allows for Faster and Less Disruptive Construction
Durable Polyethylene Basin for Extended Life and Rock Shaped Cover for Cohesion with Landscape
Discharge Valve Accessible from Top Of POD, Removing Need for Basin Entry
Pump and Level Controls can be Removed Independently, and Both Feature a Plug-N-Play Cord to Simplify Service
Available Options
Rock or Flat Cover, either Vented or Flood Plain
Riser Height
Direct Burial Cable Length
ESPS or SensaPro Level Control
Important Notices
Fluid compatibility For use with liquids compatible with pump component materials. Verify chemical, temperature, and pressure compatibility before use.
Electrical Requires a properly sized grounded branch circuit and motor starter with correctly rated thermal overload protection.
Operating limits Do not exceed series pressure, temperature, and speed ratings. Operation outside rated limits causes premature seal and bearing failure.
Service Disconnect and lockout/tagout power before any service. Allow pump to cool before handling after operation.
Available Documentation
✓ Product Specification Sheet — EcoTRAN Low Pressure Sewer System
✓ Installation, Operation & Maintenance Manual (IOM)
✓ Repair Parts Manual
Need the spec sheet, IOM, or parts list? Contact PumpStop and we'll send it over.
Before You OrderConfirm HP, voltage, phase, and enclosure type are correct for your installation. All models in the EcoTRAN Low Pressure Sewer System share casing dimensions and spare parts — motor configuration is the only difference between models. For sizing guidance, chat or call (781) 281-8905.
Supplier Part Number 145027
