Description
Grundfos 97741766 - CRN 32-6 H-GC-A-V-HQQV This product is manufactured by Grundfos for various industrial applications. For more information on specifications and applications please chat or call our team.
Approvals on nameplate
CE
Bearing 1
Graflon
Code for rubber
V
Code for shaft seal
HQQV
Connect code
GC
Connection
PN 40
Curve tolerance
ISO9906:2012 3B
Flange rating inlet
300 lb
Flange size for motor
284TC
Frequency converter
NONE
Gross weight
278.0 lb
Impeller
Stainless steel
Impellers
0
Liquid max temp
194°F
Liquid temperature range
-4 .. 194 °F
Low NPSH
N
Material code
A
Maximum head
536.8 ft
Maximum operating pressure
435.11 psi
Model
B
Motor
284TC
Motor standard
NEMA
n rpm
3521rpm
Net weight
179.0 lb
Number of reduced-diameter impellers
0
Pressure rating for connection
PN 40
Pressure sensor
N
Pump
Y
Pump version
H
Rated flow
136 US gpm
Rated head
435.7 ft
Rubber
V
Sales region
USA
Shaft
Product name:CRN 32-6 H-GC-A-V-HQQV
Shaft seal
HQQV
Stages
6
Standard
NEMA
Support bearing
Graflon
Version
H
Motor Curves
