EAN
5700395171563
Applications
Industrial applications
Approvals
CURUS
Bearing 1
SIC
Built-in motor protection
NONE
Code for rubber
V
Code for shaft seal
HQQV
Connect code
CA
Connection
FlexiClamp
Connection 2
DN 32
Connection 3
DN 32
Connection 4
PN 25
Cooling
TEFC
Curve tolerance
ISO9906:2012 3B
Density
62.29 lb/ft³
Enclosure class (IEC 34-5)
55 Dust/Jetting
Eta 1/1
84.1-83.5%
Flange size for motor
56C
Frequency
60 HZ
Frequency converter
NONE
Full load SF current
5,1-4,95/2,48 A
Gross weight
63.1 lb
IE Eff. Class
NEMA Premium / IE3 60Hz
IE efficiency
classNEMA Premium / IE3 60Hz
IE Efficiency class
NEMA Premium / IE3 60Hz
Impeller
Stainless steel
Impellers
13
Insulation
F
Insulation class (IEC 85)
F
Liquid max temp
90°C
Liquid temperature range
-4 .. 194 °F
Low NPSH
N
Material code
A
Material Pricing Group
6
Max pressure at stated temp
363 psi / 194 °F
Maximum ambient temperature
140 °F
Maximum head
380.3 ft
Maximum operating pressure
362.59 psi
Maximum permissible operating pressure
25bar
Model
A
Motor
56C
Motor efficiency at 1/2 load
0.82
Motor efficiency at 3/4 load
83.5-81.0 %
Motor efficiency at full load 1
84.1-83.5 %
Motor protec
NONE
Motor standard
NEMA
Motor type
80CA
n rpm
3440-3480rpm
Net weight
52.1 lb
Number of poles
2
Number of reduced-diameter impellers
0
P2 HP
1.5 HP
P2 kW
1.1kW
Phase
3
Power (P2) required by pump
1.5 HP
Power factor 1
0.84-0.78
Pressure rating
PN 25
Pressure rating for connection
PN 25
Product family
CRI 1
Pump
1.5 HP
Pump housing
Stainless steel
Pump inlet
DN 32
Pump outlet
DN 32
Pump version
A
Pumped liquid
Water
Rated current
4,45-4,3/2,16 A
Rated flow
9.69 US gpm
Rated flow 2
9.69 US gpm
Rated head
283.8 ft
Rated head 2
283.8 ft
Rated power - P2
1.5 HP
Rated speed
3440-3480 rpm
Rated voltage
3 x 208-230YY/460Y V
Real Time
Delivery date to be confirmed on Sales Order Update with real time availability and Net price
Rubber
V
Selected liquid temperature
68 °F
Service factor
1.15
Shaft seal
HQQV
Size of inlet connection
DN 32
Size of outlet connection
DN 32
Stages
13
Standard
NEMA
Starting current
7.2
Type
80CA
Type of connection
FlexiClamp
Version
A
