EAN
        5700395170610















        Applications
        Industrial applications










            Approvals

              CURUS








            Approvals for drinking water

              NSF/ANSI 61








            Bearing 1

              SIC








            Built-in motor protection

              NONE








            Code for rubber

              E








            Code for shaft seal

              HQQE








            Connect code

              CA








            Connection

              FlexiClamp








            Connection 2

              DN 32








            Connection 3

              DN 32








            Connection 4

              PN 25








            Cooling

              TEFC








            Curve tolerance

              ISO9906:2012 3B








            Density

              62.29 lb/ft³














            Enclosure class (IEC 34-5)

              55  Dust/Jetting








            Eta 1/1

              84.1-83.5%








            Flange size for motor

              56C








            Frequency

              60 HZ








            Frequency converter

              NONE








            Full load SF current

              5,1-4,95/2,48 A








            Gross weight




              63.1 lb








            IE Eff. Class

              NEMA Premium / IE3 60Hz








            IE efficiency

              classNEMA Premium / IE3 60Hz








            IE Efficiency class

              NEMA Premium / IE3 60Hz








            Impeller

              Stainless steel








            Impellers

              13








            Insulation

              F








            Insulation class (IEC 85)

              F










            Liquid max temp

              120°C








            Liquid temperature range

              -4 .. 248 °F








            Low NPSH

              N








            Material code

              A








            Material Pricing Group

              30








            Max pressure at stated temp

              363 psi / 250 °F








            Maximum ambient temperature

              140 °F








            Maximum head

              380.3 ft








            Maximum operating pressure

              362.59 psi








            Maximum permissible operating pressure

              25bar








            Model

              A








            Motor

              56C








            Motor efficiency at 1/2 load

              0.82








            Motor efficiency at 3/4 load

              83.5-81.0 %








            Motor efficiency at full load 1

              84.1-83.5 %








            Motor protec

              NONE








            Motor standard

              NEMA








            Motor type

              80CA








            n rpm

              3440-3480rpm








            Net weight




              52.1 lb








            Number of poles

              2








            Number of reduced-diameter impellers

              0








            P2 HP

              1.5 HP








            P2 kW

              1.1kW








            Phase

              3








            Power (P2) required by pump

              1.5 HP








            Power factor 1

              0.84-0.78








            Pressure rating

              PN 25








            Pressure rating for connection

              PN 25








            Product family

              CRI 1








            Pump

              1.5 HP








            Pump housing

              Stainless steel








            Pump inlet

              DN 32








            Pump outlet

              DN 32








            Pump version

              A








            Pumped liquid

              Water








            Rated current

              4,45-4,3/2,16 A








            Rated flow

              9.69 US gpm








            Rated flow 2

              9.69 US gpm








            Rated head

              283.8 ft








            Rated head 2

              283.8 ft








            Rated power - P2

              1.5 HP








            Rated speed

              3440-3480 rpm








            Rated voltage

              3 x 208-230YY/460Y V








            Real Time

              Delivery date to be confirmed on Sales Order Update with real time availability and Net price








            Rubber

              E








            Selected liquid temperature

              68 °F








            Service factor

              1.15








            Shaft seal

              HQQE








            Size of inlet connection

              DN 32








            Size of outlet connection

              DN 32








            Stages

              13








            Standard

              NEMA








            Starting current

              7.2








            Type

              80CA








            Type of connection

              FlexiClamp








            Version

              A
