EAN
5700395183023
Applications
Industrial applications
Approvals
CURUS
Bearing 1
SIC
Built-in motor protection
NONE
Code for rubber
V
Code for shaft seal
HQQV
Connect code
B
Connection
Oval / NPT(F)
Connection 2
PN 16
Cooling
TEFC
Curve tolerance
ISO9906:2012 3B
Density
62.29 lb/ft³
Enclosure class (IEC 34-5)
55 Dust/Jetting
Eta 1/1
77.0-77.0%
Flange size for motor
56C
Frequency
60 HZ
Frequency converter
NONE
Full load SF current
4,0-3,9/1,95 A
Gross weight
60.6 lb
IE Eff. Class
NEMA Premium / IE3 60Hz
IE efficiency
classNEMA Premium / IE3 60Hz
IE Efficiency class
NEMA Premium / IE3 60Hz
Impeller
Stainless steel
Impellers
6
Insulation
F
Insulation class (IEC 85)
F
Liquid max temp
90°C
Liquid temperature range
-4 .. 194 °F
Low NPSH
N
Material code
A
Material Pricing Group
30
Max pressure at stated temp
232 psi / 194 °F
Maximum ambient temperature
140 °F
Maximum head
187 ft
Maximum operating pressure
232.06 psi
Maximum permissible operating pressure
16bar
Model
A
Motor
56C
Motor efficiency at 1/2 load
78.5-76.0 %
Motor efficiency at 3/4 load
81.0-80.0 %
Motor efficiency at full load 1
77.0-77.0 %
Motor protec
NONE
Motor standard
NEMA
Motor type
71BB
n rpm
3430-3460rpm
Net weight
49.6 lb
Number of poles
2
Number of reduced-diameter impellers
0
P2 HP
1 HP
P2 kW
0.75kW
Phase
3
Power (P2) required by pump
1 HP
Power factor 1
0.81-0.72
Pressure rating
PN 16
Pressure rating for connection
PN 16
Product family
CR 3
Pump
1 HP
Pump housing
Cast iron
Pump inlet
1
Pump outlet
1
Pump version
A
Pumped liquid
Water
Rated current
3,25-3,35/1,68 A
Rated flow
15.4 US gpm
Rated flow 2
15.4 US gpm
Rated head
137.5 ft
Rated head 2
137.5 ft
Rated power - P2
1 HP
Rated speed
3430-3460 rpm
Rated voltage
3 x 208-230YY/460Y V
Real Time
Delivery date to be confirmed on Sales Order Update with real time availability and Net price
Rubber
V
Selected liquid temperature
68 °F
Service factor
1.25
Shaft seal
HQQV
Stages
6
Standard
NEMA
Starting current
590-650 %
Type
71BB
Type of connection
Oval / NPT(F)
Version
A
