Baldor M3355 - .17 HP, 1725RPM, 3 Phase, 60HZ, 42, 3316M, TEFC, F1 60HZ Three Phase Three Phase 17 HP 3316 M Cable

Save $175.25
BaldorSKU: M3355

Price:
Sale price$525.75 Regular price$701.00
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Baldor M3355 - .17 HP Three Phase Enclosed Motor

Discover the reliability and efficiency of the Baldor M3355, a .17 HP, 1725 RPM three-phase motor designed for optimal performance in various applications. This motor operates at 60HZ and features a TEFC (Totally Enclosed Fan Cooled) design, ensuring durability and protection against environmental factors.

Specifications:

  • Power: .17 HP
  • Speed: 1725 RPM
  • Phase: 3 Phase
  • Frequency: 60HZ
  • Frame: 42
  • Model: 3316M
  • Type: Enclosed

As a trusted vendor, Baldor provides high-quality motors that are ideal for various industrial and commercial applications. The M3355 is perfect for those seeking a reliable and efficient solution for their pumping needs.

At Pump-Stop.com, we are your preferred source for replacement pumps and parts. If you have questions or need assistance in finding the right pump for your application, please call us at (781) 281-8905. We recommend checking your current pump for the exact part number or SKU that matches the Baldor M3355 to ensure compatibility. If you encounter any difficulties, our team is here to help you find the right item.

UPC 781568101759
Supplier Part Number M3355
Category AC Motors
Subcategory Three Phase Enclosed
Product Family General Purpose
Agency Approvals C UR US
Ambient Temperature 40 °C
Approximate Weight (lbs) 17.0
Auxillary Box No Auxillary Box
Auxillary Box Lead Termination None
Base Indicator Rigid
Bearing Grease Type Polyrex EM (-20F +300F)
Blower None
Catalog Number M3355
Current @ Voltage .600 A @ 460.0 V, 1.200 A @ 230.0 V, 1.400 A @ 208.0 V
Design Code -
Drip Cover No Drip Cover
Duty Rating CONT
Efficiency @ 100% Load 62.0 %
Electrically Isolated Bearing Not Electrically Isolated
Enclosure TEFC
Feedback Device NO FEEDBACK
Feedback Signal NONE
Frame 42
Frame Material Steel
Frequency 60.00 Hz
Front Face Code Standard
Front Shaft Indicator None
Heater Indicator No Heater
High Voltage Full Load Amps 0.6 a
Insulation Class B
Inverter Code Not Inverter
IP Rating NONE
KVA Code -
Lifting Lugs No Lifting Lugs
Locked Bearing Indicator No Locked Bearing
Motor Lead Exit Ko Box
Motor Lead Quantity/Wire Size 9 @ 18 AWG
Motor Lead Termination Flying Leads
Motor Letter Type Three Phase
Motor Standards NEMA
Motor Type 3316M
Mounting Arrangement F1
Number of Poles 4
Output 0.170 hp
Output @ Frequency .170 HP @ 60 HZ
Overall Length 9.56 IN
Phase 3
Power Factor 51
Pulley End Bearing Type Ball
Pulley Face Code Standard
Pulley Shaft Indicator Standard
Rodent Screen None
RoHS Status ROHS COMPLIANT
Service Factor 1.35
Shaft Diameter 0.375 IN
Shaft Extension Location Pulley End
Shaft Ground Indicator No Shaft Grounding
Shaft Rotation Reversible
Shaft Slinger Indicator No Slinger
Speed 1725 rpm
Speed Code Single Speed
Starting Method Direct on line
Synchronous Speed 1,800 rpm
Synchronous Speed @ Frequency 1800 RPM @ 60 HZ
Thermal Device - Bearing None
Thermal Device - Winding None
Vibration Sensor Indicator No Vibration Sensor
Voltage 230 V, 460 V
Voltage @ Frequency 460.0 V @ 60 HZ, 230.0 V @ 60 HZ
Winding Thermal 1 None
Winding Thermal 2 None

Motor Curves
