Description
CRN 32-6 A-G-A-E-HQQE | Vertical, multistage centrifugal pump with inlet and outlet ports on same the level (inline). Pump materials in contact with the liquid are in high-grade stainless steel. A cartridge shaft seal ensures high reliability, safe handling, and easy access and service. Power transmission is via a rigid split coupling. Pipe connection is via ANSI flanges.
EAN
5700390670160
Applications
Industrial applications
Actual impeller diameter
4.66 in
Approvals
CE
Approvals for drinking water
NSF/ANSI 61
Bearing 1
SIC
Code for rubber
E
Code for shaft seal
HQQE
Connect code
G
Connection
ANSI
Connection 2
PN 40
Curve tolerance
ISO9906:2012 3B
Density
62.29 lb/ft³
Diameter
4.66 in
DOE Pump Energy Index CL
0.87
Flange rating inlet
300 lb
Flange size for motor
284TC
Flange standard
ANSI
Frequency
60 HZ
Frequency converter
NONE
Gross weight
180.0 lb
Impeller
Stainless steel
Impellers
6
Liquid max temp
120°C
Liquid temperature range
-40 .. 248 °F
Low NPSH
N
Material code
A
Material Pricing Group
6
Max pressure at stated temp
435 psi / 250 °F
Maximum head
553.5 ft
Maximum operating pressure
435.11 psi
Maximum permissible operating pressure
30bar
Model
B
Motor
284TC
Motor standard
NEMA
n rpm
3521rpm
Net weight
162.0 lb
Number of reduced-diameter impellers
0
Power (P2) required by pump
25 HP
Pressure rating
PN 40
Pressure rating for connection
PN 40
Product family
CRN 32
Pump
25 HP
Pump housing
Stainless steel
Pump inlet
2.5
Pump outlet
2.5
Pump version
A
Pumped liquid
Water
Rated flow
159 US gpm
Rated flow 2
159 US gpm
Rated head
429.5 ft
Rated head 2
429.5 ft
Real Time
Delivery date to be confirmed on Sales Order Update with real time availability and Net price
Rubber
E
Sales region
Namreg
Selected liquid temperature
68 °F
Shaft seal
HQQE
Stages
6
Standard
NEMA
Support bearing
Graflon
Type of connection
ANSI
Version
A
