EAN
5715114126885
Applications
Industrial applications
Actual impeller diameter
4.13 in
Approvals
CURUS
Bearing 1
SIC
Built-in motor protection
NONE
Code for rubber
V
Code for shaft seal
HQQV
Connect code
P
Connection
PJE
Connection 2
DN 50
Connection 3
DN 50
Connection 4
PN 50
Cooling
IC 411
Curve tolerance
ISO9906:2012 3B
Density
62.29 lb/ft³
Diameter
4.13 in
DOE Pump Energy Index CL
0.91
Enclosure class (IEC 34-5)
IP55
Eta 1/1
0.865
Flange size for motor
213TC
Frequency
60 HZ
Frequency converter
NONE
Full load SF current
42.5/43.8 A
Gross weight
262.0 lb
IE efficiency
0.865
Impeller
Stainless steel
Impellers
4
Insulation
F
Insulation class (IEC 85)
F
Liquid max temp
90°C
Liquid temperature range
-4 .. 194 °F
Low NPSH
N
Material code
A
Material Pricing Group
6
Max pressure at stated temp
363 psi / 194 °F
Maximum ambient temperature
104 °F
Maximum head
274.3 ft
Maximum operating pressure
362.59 psi
Maximum permissible operating pressure
25bar
Model
A
Motor
213TC
Motor efficiency at 1/2 load
0.815
Motor efficiency at 3/4 load
0.855
Motor efficiency at full load 1
0.865
Motor protec
NONE
Motor standard
NEMA
Motor type
WEG
n rpm
3510rpm
Net weight
243.0 lb
Number of poles
2
Number of reduced-diameter impellers
0
P2 HP
10 HP
P2 kW
7.5kW
Phase
1
Power (P2) required by pump
10 HP
Power factor 1
0.99
Pressure rating
PN 50
Pressure rating for connection
PN 50
Product family
CRN 20
Pump
10 HP
Pump housing
Stainless steel
Pump inlet
DN 50
Pump outlet
DN 50
Pump version
A
Pumped liquid
Water
Rated current
42.5-38.1 A
Rated flow
111 US gpm
Rated flow 2
111 US gpm
Rated head
210.3 ft
Rated head 2
210.3 ft
Rated power - P2
10 HP
Rated speed
3510 rpm
Rated voltage
1 x 208-230 V
Real Time
Delivery date to be confirmed on Sales Order Update with real time availability and Net price
Rubber
V
Selected liquid temperature
68 °F
Service factor
1.15
Shaft seal
HQQV
Size of inlet connection
DN 50
Size of outlet connection
DN 50
Stages
4
Standard
NEMA
Starting current
720-720 %
Type
WEG
Type of connection
PJE
Version
A
