EAN
        5715114121422















        Applications
        Industrial applications








            Actual impeller diameter

              3.66 in










            Approvals

              CURUS








            Bearing 1

              SIC








            Built-in motor protection

              NONE








            Code for rubber

              V








            Code for shaft seal

              HQQV








            Connect code

              P








            Connection

              PJE








            Connection 2

              DN 50








            Connection 3

              DN 50








            Connection 4

              PN 50








            Cooling

              IC 411








            Curve tolerance

              ISO9906:2012 3B








            Density

              62.29 lb/ft³








            Diameter

              3.66 in












            DOE Pump Energy Index CL

              0.87










            Enclosure class (IEC 34-5)

              IP55








            Eta 1/1

              0.84








            Flange size for motor

              213TC








            Frequency

              60 HZ








            Frequency converter

              NONE








            Full load SF current

              31.7/44.6 A








            Gross weight




              260.0 lb








            IE efficiency

              0.84








            Impeller

              Stainless steel








            Impellers

              8








            Insulation

              F








            Insulation class (IEC 85)

              F










            Liquid max temp

              90°C








            Liquid temperature range

              -4 .. 194 °F








            Low NPSH

              N








            Material code

              A








            Material Pricing Group

              6








            Max pressure at stated temp

              363 psi / 194 °F








            Maximum ambient temperature

              104 °F








            Maximum head

              387.2 ft








            Maximum operating pressure

              362.59 psi








            Maximum permissible operating pressure

              25bar








            Model

              A








            Motor

              213TC










            Motor efficiency at 1/2 load

              0.785








            Motor efficiency at 3/4 load

              0.825








            Motor efficiency at full load 1

              0.84








            Motor protec

              NONE








            Motor standard

              NEMA








            Motor type

              WEG








            n rpm

              3515rpm








            Net weight




              240.0 lb








            Number of poles

              2








            Number of reduced-diameter impellers

              0








            P2 HP

              7.5 HP








            P2 kW

              5.5kW








            Phase

              1








            Power (P2) required by pump

              7.5 HP








            Power factor 1

              0.99








            Pressure rating

              PN 50








            Pressure rating for connection

              PN 50








            Product family

              CRN 10








            Pump

              7.5 HP








            Pump housing

              Stainless steel








            Pump inlet

              DN 50








            Pump outlet

              DN 50








            Pump version

              A








            Pumped liquid

              Water








            Rated current

              31.7-28.8 A








            Rated flow

              53.3 US gpm








            Rated flow 2

              53.3 US gpm








            Rated head

              310.7 ft








            Rated head 2

              310.7 ft








            Rated power - P2

              7.5 HP








            Rated speed

              3515 rpm








            Rated voltage

              1 x 208-230 V








            Real Time

              Delivery date to be confirmed on Sales Order Update with real time availability and Net price








            Rubber

              V








            Selected liquid temperature

              68 °F








            Service factor

              1.15








            Shaft seal

              HQQV








            Size of inlet connection

              DN 50








            Size of outlet connection

              DN 50








            Stages

              8








            Standard

              NEMA








            Starting current

              710-710 %








            Type

              WEG








            Type of connection

              PJE








            Version

              A
