Grundfos 97994170 - CRI 15-9 A-P-A-E-HQQE | Vertical | Multistage | Centrifugal

GRUNDFOSSKU: 97994170

Contact for price
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Grundfos 97994170 - CRI 15-9 A-P-A-E-HQQE Vertical Multistage Centrifugal Pump

The Grundfos 97994170 - CRI 15-9 A-P-A-E-HQQE is a high-performance vertical multistage centrifugal pump designed for a variety of industrial applications. Engineered by Grundfos, a leader in pump technology, this model ensures efficient operation and reliability in demanding environments.

With its robust construction and advanced design, the CRI 15-9 A-P-A-E-HQQE is ideal for high-pressure applications, making it a perfect choice for those seeking durability and performance. This pump is categorized under Service Special and is part of the Grundfos Centrifugal Pumps range, specifically tailored for both single and multi-stage operations.

At Pump-Stop.com, we pride ourselves on being the preferred source for replacement pumps and parts. If you have questions or need assistance in finding the right pump for your application, please don't hesitate to reach out to our knowledgeable team at (781) 281-8905.

Before purchasing, we recommend checking your current pump for the exact part number or SKU to ensure compatibility. If you encounter any difficulties in locating the right item, our team is here to help!

EAN 5710627558796
Actual impeller diameter 104.8 mm
Approvals CURUS
Approvals for drinking water NSF/ANSI 61
Built-in motor protection NONE
Code for rubber E
Code for shaft seal HQQE
Connect code P
Connection PN 50
Curve tolerance ISO9906:2012 3B
Density 998.2 kg/m³
Diameter 104.8 mm
DOE Pump Energy Index CL 0.91
Enclosure class (IEC 34-5) IP54
Flange size for motor 254TC
Frequency converter NONE
Gross weight 227.0 kg
IE efficiency IE3 92
IE Efficiency class IE3 / NEMA Premium
Impeller Stainless steel
Impellers 0
Insulation class (IEC 85) F
Liquid temperature range -20 .. 120 °C
Low NPSH N
Mains frequency 60 Hz
Material code A
Material Pricing Group 30
Max pressure at stated temp 25 bar / 120 °C
Maximum ambient temperature 40 °C
Maximum head 180 m
Maximum operating pressure 25 bar
Model A
Motor 254TC
Motor efficiency at full load 1 0.924
Motor standard NEMA
Motor type BALDOR
Net weight 175.0 kg
Number of poles 2
Number of reduced-diameter impellers 0
Power (P2) required by pump 15 kW
Pressure rating for connection PN 50
Pressure sensor N
Pump 15 kW
Pump speed on which pump data are based 3444 rpm
Pump version A
Pumped liquid Water
Rated current 48-44/22 A
Rated flow 20.5 m³/h
Rated head 138.1 m
Rated power - P2 15 kW
Rated speed 3540 rpm
Rated voltage 3 x 208-230/460 V
Real Time Delivery date to be confirmed on Sales Order  Update with real time availability and Net price
Rubber E
Selected liquid temperature 20 °C
Service factor 1.15
Size of inlet connection DN 50
Size of outlet connection DN 50
Stages 9
Standard NEMA
Type BALDOR
Type of connection PJE
Version A

Motor Curves

Dimensional Drawing

DWiring Diagram
