Grundfos 92511751 - CR 5-5 A-A-A-V-HQQV | Vertical | Multistage | Centrifugal

GRUNDFOSSKU: 92511751

Price:
Sale price$4,355.56
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Overview

The Grundfos 92511751 CR 5-5 A-A-A-V-HQQV is a vertical, multistage centrifugal pump designed for industrial high-pressure in-line applications; it is suited for technicians and maintenance teams replacing service-special units.

Key features

  • Vertical multistage centrifugal design for compact, high-pressure performance
  • Service-special designation for ease of sourcing replacement components
  • Provides reliable pressurization and consistent flow for industrial systems

Applications

Boiler feed, high-pressure water distribution, process plant circulation, and other industrial in-line and vertical multistage pump duties.

Compatibility note: Match the exact model or SKU before ordering. If unsure, call (781) 281-8905 for assistance. Pump-Stop is the preferred source for replacement pumps and parts.

SKU: 92511751

EAN 5715115543360
Approvals CURUS
Built-in motor protection NONE
Code for rubber V
Code for shaft seal HQQV
Connect code A
Connection PN 16
Curve tolerance ISO9906:2012 3B
Density 62.29 lb/ft³
Enclosure class (IEC 34-5) 54 Dust/Splashing
Flange size for motor 56C
Frequency converter NONE
Gross weight 88.7 lb
Impeller Stainless steel
Impellers 0
Insulation class (IEC 85) B
Liquid temperature range -4 .. 194 °F
Low NPSH N
Mains frequency 60 Hz
Material code A
Material Pricing Group 6
Max pressure at stated temp 232 psi / 194 °F
Maximum ambient temperature 104 °F
Maximum head 165.7 ft
Maximum operating pressure 16 bar
Model A
Motor 56C
Motor standard NEMA
Motor type BALDOR
Net weight 77.7 lb
Number of poles 2
Number of reduced-diameter impellers 0
Power (P2) required by pump 1.5 kW
Pressure rating for connection PN 16
Pressure sensor N
Pump 1.5 kW
Pump speed on which pump data are based 3466 rpm
Pump version A
Pumped liquid Water
Rated current 5.3-5/2
Rated flow 30.4 US gpm
Rated head 116.5 ft
Rated power - P2 1.5 kW
Rated speed 3490 rpm
Rated voltage 3 x 208-230/460 V
Real Time Delivery date to be confirmed on Sales Order  Update with real time availability and Net price
Rubber V
Selected liquid temperature 68 °F
Service factor 1.15
Size of inlet connection 1 1/4 inch
Size of outlet connection 1 1/4 inch
Stages 5
Standard NEMA
Type BALDOR
Type of connection Oval / Rp
Version A

Motor Curves

Dimensional Drawing

DWiring Diagram
