Description
CR 45-5 K-G-A-E-HQQE | Vertical, multistage centrifugal pump with inlet and outlet ports on same the level (inline). The pump head and base are in cast iron – all other wetted parts are in stainless steel. A special "Low NPSH" first-stage design reduces the pump's NPSHr value. A cartridge shaft seal ensures high reliability, safe handling, and easy access and service. Power transmission is via a rigid split coupling. Pipe connection is via ANSI flanges. The pump is fitted with a 3-phase, fan-cooled asynchronous motor.
EAN
5715114889452
Applications
Industrial applications
Material Pricing Group
3L
Motor efficiency at full load 1
0.93
IE Efficiency class
IE3 / NEMA Premium
Code for rubber
E
Maximum ambient temperature
104 °F
Material code
A
Density
62.29 lb/ft³
Max pressure at stated temp
435 psi / 250 °F
Maximum operating pressure
435.11 psi
Power factor 1
0.89
Support bearing
Graflon
Selected liquid temperature
68 °F
Type of connection
ANSI
Bearing 1
SIC
Pressure rating
PN 40
Rated voltage
3 x 230/460 V
Flange size for motor
324TC
Pumped liquid
Water
Starting current
6.2
Pump outlet
3
Pump inlet
3
Connect code
G
Liquid temperature range
-22 .. 248 °F
Insulation class (IEC 85)
F
IE efficiency
IE3 93%
Motor efficiency at 1/2 load
0.93
Built-in motor protection
NONE
Net weight
769.0 lb
Number of poles
2
Rated speed
3550 rpm
Gross weight
787.0 lb
Rated power - P2
50 HP
Enclosure class (IEC 34-5)
IP55
Power (P2) required by pump
50 HP
Pressure rating for connection
PN 40
Motor efficiency at 3/4 load
0.93
Rated current
112/56.1 A
Service factor
1.25
Full load SF current
140/70.1 A
Frequency converter
NONE
Motor type
WEG
DOE Pump Energy Index CL
0.89
Stages
5
Approvals
CURUS
Rated flow
238 US gpm
Model
B
Version
K
Diameter
5.37 in
Cooling
IC 411
Motor
324TC
Rubber
E
Maximum head
606.3 ft
Motor standard
NEMA
Rated head
480.7 ft
Actual impeller diameter
5.37 in
Type
WEG
Curve tolerance
ISO9906:2012 3B
Impellers
5
Connection
ANSI
Impeller
Stainless steel
Code for shaft seal
HQQE
Pump housing
Cast iron
Number of reduced-diameter impellers
0
Flange rating inlet
300 lb
Pump
50 HP
Low NPSH
Y
Standard
NEMA
Pump version
K
