EAN
5715114889445
Applications
Industrial applications
Actual impeller diameter
5.37 in
Approvals
CURUS
Bearing 1
SIC
Built-in motor protection
NONE
Code for rubber
E
Code for shaft seal
HQQE
Connect code
G
Connection
ANSI
Connection 2
PN 40
Cooling
IC 411
Curve tolerance
ISO9906:2012 3B
Density
62.29 lb/ft³
Diameter
5.37 in
DOE Pump Energy Index CL
0.89
Enclosure class (IEC 34-5)
IP55
Eta 1/1
0.93
Flange rating inlet
300 lb
Flange size for motor
324TC
Frequency
60 HZ
Frequency converter
NONE
Full load SF current
140/70.1 A
Gross weight
787.0 lb
IE Eff. Class
IE3 / NEMA Premium
IE efficiency
IE3 93%
IE Efficiency class
IE3 / NEMA Premium
Impeller
Stainless steel
Impellers
5
Insulation
F
Insulation class (IEC 85)
F
Liquid max temp
120°C
Liquid temperature range
-22 .. 248 °F
Low NPSH
Y
Material code
A
Material Pricing Group
3L
Max pressure at stated temp
435 psi / 250 °F
Maximum ambient temperature
104 °F
Maximum head
582.4 ft
Maximum operating pressure
435.11 psi
Maximum permissible operating pressure
30bar
Model
B
Motor
324TC
Motor efficiency at 1/2 load
0.93
Motor efficiency at 3/4 load
0.93
Motor efficiency at full load 1
0.93
Motor protec
NONE
Motor standard
NEMA
Motor type
WEG
n rpm
3550rpm
Net weight
769.0 lb
Number of poles
2
Number of reduced-diameter impellers
1
P2 HP
50 HP
P2 kW
37kW
Phase
3
Power (P2) required by pump
50 HP
Power factor 1
0.89
Pressure rating
PN 40
Pressure rating for connection
PN 40
Product family
CR 45
Pump
50 HP
Pump housing
Cast iron
Pump inlet
3
Pump outlet
3
Pump version
K
Pumped liquid
Water
Rated current
112/56.1 A
Rated flow
238 US gpm
Rated flow 2
238 US gpm
Rated head
461.6 ft
Rated head 2
461.6 ft
Rated power - P2
50 HP
Rated speed
3550 rpm
Rated voltage
3 x 230/460 V
Real Time
Delivery date to be confirmed on Sales Order Update with real time availability and Net price
Rubber
E
Selected liquid temperature
68 °F
Service factor
1.25
Shaft seal
HQQE
Stages
5
Standard
NEMA
Starting current
6.2
Support bearing
Graflon
Type
WEG
Type of connection
ANSI
Version
K
