Grundfos 99392968 - CR 45-1 A-F-A-E-HQQE | Multistage | Centrifugal | Vertical | Inline

GRUNDFOSSKU: 99392968

Price:
Sale price$6,458.33
or Call for most up to date lead times. (781) 281-8905

Description

CR 45-1 A-F-A-E-HQQE Vertical, multistage centrifugal pump with inlet and outlet ports on same the level (inline). The pump head and base are in cast iron – all other wetted parts are in stainless steel. A cartridge shaft seal ensures high reliability, safe handling, and easy access and service. Power transmission is via a rigid split coupling. Pipe connection is via DIN flanges.

EAN 5713828384393
Actual impeller diameter 5.34 in
Approvals CE
Bearing 1 Graflon
Code for rubber E
Code for shaft seal HQQE
Connect code F
Connection PN 40
Curve tolerance ISO9906:2012 3B
Diameter 5.34 in
DOE Pump Energy Index CL 0.89
Flange size for motor 213TC
Frequency converter NONE
Gross weight 149.0 lb
Impeller Stainless steel
Impellers 0
Liquid temperature range -22 .. 248 °F
Low NPSH N
Material code A
Material Pricing Group 6
Max pressure at stated temp 232 psi / 250 °F
Maximum head 126.6 ft
Maximum operating pressure 16 bar
Model B
Motor 213TC
Motor standard NEMA
Net weight 131.0 lb
Number of reduced-diameter impellers 0
Pressure rating for connection PN 40
Pressure sensor N
Pump speed on which pump data are based 3467 rpm
Pump version A
Rated flow 238 US gpm
Rated head 92.2 ft
Real Time Delivery date to be confirmed on Sales Order  Update with real time availability and Net price
Rubber E
Size of inlet connection DN 80
Size of outlet connection DN 80
Stages 1
Standard NEMA
Support bearing Graflon
Type of connection DIN
Version A

Motor Curves

Dimensional Drawing
