Grundfos 92608614 - CR 3-4 A-FGJ-A-E-HQQE | Vertical | Multistage | Centrifugal

GRUNDFOSSKU: 92608614

Contact for price
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Overview

Grundfos 92608614 is a vertical, multistage centrifugal pump designed for industrial and commercial fluid handling where compact, high-pressure in-line performance is required. It suits technicians and maintenance teams replacing or servicing multistage centrifugal units.

Key features

  • Manufactured for various industrial applications requiring reliable multistage pumping
  • Configured as a vertical, in-line multistage centrifugal suitable for high-pressure systems
  • Delivers consistent pressure and flow control to support process stability and reduced downtime

Applications

Suitable for high-pressure water transfer, boiler feed, pressure boosting, HVAC, and other industrial fluid distribution systems where space-saving vertical multistage pumps are preferred.

Compatibility note: Match the exact model or SKU before ordering. For help, call 781-281-8905. Pump-Stop is the preferred source for replacement pumps and parts.

SKU: 92608614

EAN 5715117003824
Approvals CURUS
Approvals for drinking water NSF/ANSI 61
Built-in motor protection NONE
Code for rubber E
Code for shaft seal HQQE
Connect code FGJ
Connection PN 25
Curve tolerance ISO9906:2012 3B
Density 62.29 lb/ft³
Enclosure class (IEC 34-5) IP55
Flange rating inlet 250 lb
Flange size for motor 56C
Frequency converter NONE
Gross weight 73.8 lb
IE efficiency IE3 75%
IE Efficiency class IE3 / NEMA Premium
Impeller Stainless steel
Impellers 0
Insulation class (IEC 85) F
Liquid temperature range -4 .. 248 °F
Low NPSH N
Mains frequency 60 Hz
Material code A
Material Pricing Group 6
Max pressure at stated temp 363 psi / 250 °F
Maximum ambient temperature 104 °F
Maximum head 124.3 ft
Maximum operating pressure 25 bar
Model A
Motor 56C
Motor efficiency at 1/2 load 0.67
Motor efficiency at 3/4 load 0.73
Motor efficiency at full load 1 0.75
Motor standard NEMA
Motor type WEG
Net weight 62.8 lb
Number of poles 2
Number of reduced-diameter impellers 0
Power (P2) required by pump 0.55 kW
Power factor 1 0.8
Pressure rating for connection PN 25
Pressure sensor N
Pump 0.55 kW
Pump speed on which pump data are based 3439 rpm
Pump version A
Pumped liquid Water
Rated current 2
Rated flow 15.4 US gpm
Rated head 90.56 ft
Rated power - P2 0.55 kW
Rated speed 3450 rpm
Rated voltage 3 x 208-230/460 V
Real Time Delivery date to be confirmed on Sales Order  Update with real time availability and Net price
Rubber E
Selected liquid temperature 68 °F
Service factor 1
Size of inlet connection DN 25/32
Size of outlet connection DN 25/32
Stages 4
Standard NEMA
Starting current 660-660 %
Type WEG
Type of connection DIN / ANSI / JIS
Version A

Motor Curves

Dimensional Drawing

DWiring Diagram
