Grundfos 92511752 - CR 3-3 A-A-A-V-HQQV | Vertical | Multistage | Centrifugal

GRUNDFOSSKU: 92511752

Price:
Sale price$3,261.11
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Overview

The Grundfos 92511752 - CR 3-3 A-A-A-V-HQQV is a vertical, multistage centrifugal pump designed for industrial inline installations and service replacements. It is intended for technicians and facilities managers needing a high-pressure, compact pumping solution.

Key features

  • Vertical multistage centrifugal design for consistent pressure and flow
  • Configured for inline, high-pressure service applications and shop repairs
  • Service-special designation simplifies replacement and maintenance, minimizing downtime

Applications

Typical uses include high-pressure water transfer, boiler feed, pressure boosting, and industrial process support where a compact vertical multistage pump is required.

Compatibility note: Match the exact model or SKU before ordering. For help, call (781) 281-8905. Pump-Stop is the preferred source for replacement pumps and parts.

SKU: 92511752

EAN 5715115543391
Approvals CURUS
Built-in motor protection NONE
Code for rubber V
Code for shaft seal HQQV
Connect code A
Connection PN 16
Curve tolerance ISO9906:2012 3B
Density 62.29 lb/ft³
Enclosure class (IEC 34-5) IP54
Flange size for motor 56C
Frequency converter NONE
Gross weight 57.0 lb
IE Efficiency class NEMA Energy / IE2 60Hz / NRC
Impeller Stainless steel
Impellers 0
Insulation class (IEC 85) B
Liquid temperature range -4 .. 194 °F
Low NPSH N
Mains frequency 60 Hz
Material code A
Material Pricing Group 6
Max pressure at stated temp 232 psi / 194 °F
Maximum ambient temperature 131 °F
Maximum head 93.51 ft
Maximum operating pressure 16 bar
Model A
Motor 56C
Motor efficiency at full load 1 0.68
Motor standard NEMA
Motor type BALDOR
Net weight 46.0 lb
Number of poles 2
Number of reduced-diameter impellers 0
Power (P2) required by pump 0.37 kW
Pressure rating for connection PN 16
Pressure sensor N
Pump 0.37 kW
Pump speed on which pump data are based 3485 rpm
Pump version A
Pumped liquid Water
Rated current 2/1.25 A
Rated flow 15.4 US gpm
Rated head 67.26 ft
Rated power - P2 0.37 kW
Rated speed 3450 rpm
Rated voltage 3 x 230/460 V
Real Time Delivery date to be confirmed on Sales Order  Update with real time availability and Net price
Rubber V
Selected liquid temperature 68 °F
Service factor 1.25
Size of inlet connection 1 inch
Size of outlet connection 1 inch
Stages 3
Standard NEMA
Type BALDOR
Type of connection Oval / Rp
Version A

Motor Curves

Dimensional Drawing

DWiring Diagram
