Baldor L3500 - .25 HP, 1150RPM, 1 Phase, 60HZ, 56, 3526L, TEFC, F1 60HZ Single Phase Single Phase 25 HP

Save $233.75
BaldorSKU: L3500

Price:
Sale price$701.25 Regular price$935.00
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Baldor L3500 - .25 HP Single Phase Enclosed Motor

The Baldor L3500 is a high-quality .25 HP, 1150 RPM single-phase enclosed motor designed for reliable performance in various applications. With a robust TEFC (Totally Enclosed Fan Cooled) design, this motor ensures durability and protection against dust and moisture, making it ideal for both indoor and outdoor use.

Specifications:

  • Power: .25 HP
  • Speed: 1150 RPM
  • Phase: 1 Phase
  • Frequency: 60 Hz
  • Frame: 56
  • Model: 3526L
  • Type: TEFC
  • Product Code: L3500

As a trusted supplier of replacement pumps and parts, Pump-Stop is your go-to source for the Baldor L3500 motor. If you have questions or need assistance finding the right pump for your application, please call us at (781) 281-8905. We recommend checking your current pump for the exact part number or SKU to ensure compatibility. If you’re having trouble locating the right item, our knowledgeable team is here to help!

UPC 781568100127
Supplier Part Number L3500
Category AC Motors
Subcategory Single Phase Enclosed
Product Family General Purpose
Agency Approvals C UR US
Ambient Temperature 40 °C
Approximate Weight (lbs) 30.0
Auxillary Box No Auxillary Box
Auxillary Box Lead Termination None
Base Indicator Rigid
Bearing Grease Type Polyrex EM (-20F +300F)
Blower None
Catalog Number L3500
Current @ Voltage 2.600 A @ 230.0 V, 5.200 A @ 115.0 V
Design Code N
Drip Cover No Drip Cover
Duty Rating CONT
Efficiency @ 100% Load 52.5 %
Electrically Isolated Bearing Not Electrically Isolated
Enclosure TEFC
Feedback Device NO FEEDBACK
Frame 56
Frame Material Steel
Frequency 60.00 Hz
Front Face Code Standard
Front Shaft Indicator None
Haz Area Class and Group NONE
Haz Area Division Not Applicable
Heater Indicator No Heater
High Voltage Full Load Amps 2.6 a
Insulation Class F
Inverter Code Not Inverter
IP Rating NONE
KVA Code N
Lifting Lugs No Lifting Lugs
Locked Bearing Indicator No Locked Bearing
Motor Lead Exit Ko Box
Motor Lead Quantity/Wire Size 6 @ 18 AWG
Motor Lead Termination Flying Leads
Motor Letter Type Cap Start, Induction Run
Motor Standards NEMA
Motor Type 3516L
Mounting Arrangement F1
Number of Poles 6
Output 0.250 hp
Output @ Frequency .250 HP @ 60 HZ
Overall Length 12.23 IN
Phase 1
Power Factor 56
Pulley End Bearing Type Ball
Pulley Face Code Standard
Pulley Shaft Indicator Standard
Rodent Screen None
RoHS Status ROHS COMPLIANT
Service Factor 1.35
Shaft Diameter 0.625 IN
Shaft Extension Location Pulley End
Shaft Ground Indicator No Shaft Grounding
Shaft Rotation Reversible
Shaft Slinger Indicator No Slinger
Speed 1140 rpm
Speed Code Single Speed
Starting Method Direct on line
Synchronous Speed 1,200 rpm
Synchronous Speed @ Frequency 1200 RPM @ 60 HZ
Thermal Device - Bearing None
Thermal Device - Winding None
Vibration Sensor Indicator No Vibration Sensor
Voltage 115 V, 230 V
Voltage @ Frequency 115.0 V @ 60 HZ, 230.0 V @ 60 HZ
Winding Thermal 1 None
Winding Thermal 2 None
