Baldor L1321TM - 1.5 HP, 1740RPM, 1 Phase, 60HZ, 143T, 3536L, Open, F 60HZ Single Phase Single Phase 1.5 HP

Save $345.50
BaldorSKU: L1321TM

Price:
Sale price$1,036.50 Regular price$1,382.00
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Baldor L1321TM - 1.5 HP Single Phase Open Motor

The Baldor L1321TM is a high-performance single-phase motor designed for a variety of applications. With a power output of 1.5 HP and a speed of 1740 RPM, this motor is ideal for driving pumps and other machinery that require reliable and efficient operation. It operates at 60Hz and features a 143T frame size, making it a versatile choice for both residential and commercial use.

Key Features:

  • Power: 1.5 HP
  • Speed: 1740 RPM
  • Phase: Single Phase
  • Frequency: 60Hz
  • Frame Size: 143T
  • Open design for optimal cooling

This Baldor-Reliance motor is built for durability and efficiency, ensuring long-lasting performance in demanding environments. Whether you are replacing an old motor or upgrading your equipment, the L1321TM is a reliable choice.

At Pump-Stop.com, we are your preferred source for replacement pumps and parts. If you have questions or need assistance finding the right pump for your application, please call us at (781) 281-8905. We recommend checking your current pump for the exact part number or SKU that matches the Baldor L1321TM to ensure compatibility. If you are having trouble finding the right item, our team is here to help!

UPC 781568101445
Supplier Part Number L1321TM
Category AC Motors
Subcategory Single Phase Open
Product Family General Purpose
Agency Approvals C UR US
Ambient Temperature 40 °C
Approximate Weight (lbs) 48.0
Auxillary Box No Auxillary Box
Auxillary Box Lead Termination None
Base Indicator Rigid
Bearing Grease Type Polyrex EM (-20F +300F)
Blower None
Catalog Number L1321TM
Current @ Voltage 10.500 A @ 230.0 V, 21.000 A @ 115.0 V, 9.600 A @ 208.0 V
Design Code L
Drip Cover No Drip Cover
Duty Rating CONT
Efficiency @ 100% Load 70.0 %
Electrically Isolated Bearing Not Electrically Isolated
Enclosure OPEN
Feedback Device NO FEEDBACK
Frame 145T
Frame Material Steel
Frequency 60.00 Hz
Front Face Code Standard
Front Shaft Indicator None
Haz Area Class and Group NONE
Haz Area Division Not Applicable
Heater Indicator No Heater
High Voltage Full Load Amps 9.6 a
Insulation Class F
Inverter Code Not Inverter
KVA Code M
Lifting Lugs No Lifting Lugs
Locked Bearing Indicator No Locked Bearing
Motor Lead Exit Ko Box
Motor Lead Quantity/Wire Size 4 @ 14 AWG, A&J
Motor Lead Termination Flying Leads
Motor Letter Type Cap Start, Induction Run
Motor Standards NEMA
Motor Type 3535L
Mounting Arrangement F1
Number of Poles 4
Output 1.500 hp
Output @ Frequency 1.500 HP @ 60 HZ
Overall Length 13.00 IN
Phase 1
Power Factor 64
Pulley End Bearing Type Ball
Pulley Face Code Standard
Pulley Shaft Indicator Standard
Rodent Screen None
Service Factor 1.15
Shaft Diameter 0.875 IN
Shaft Extension Location Pulley End
Shaft Ground Indicator No Shaft Grounding
Shaft Rotation Reversible
Shaft Slinger Indicator No Slinger
Speed 1725 rpm
Speed Code Single Speed
Starting Method Direct on line
Synchronous Speed 1,800 rpm
Synchronous Speed @ Frequency 1800 RPM @ 60 HZ
Thermal Device - Bearing None
Thermal Device - Winding Do Not Use
Vibration Sensor Indicator No Vibration Sensor
Voltage 230 V, 208 V, 115 V
Voltage @ Frequency 115.0 V @ 60 HZ, 208.0 V @ 60 HZ, 230.0 V @ 60 HZ
Winding Thermal 1 Manual Thermal Overload
Winding Thermal 1 Location SB
Winding Thermal 2 None

Motor Curves
