Description
Baldor Replacement Part — Cable
The Baldor EJMM4109T is a replacement cable for Baldor pump systems. An electrical power cord for submersible pump motors, rated for continuous submerged operation.
Part Specifications
| Part Number | EJMM4109T |
| Part Type | Cable |
| Brand | Baldor |
⚠ Confirm Compatibility Before OrderingAlways verify this part is correct for your specific pump model. Contact PumpStop with your pump model number and we'll confirm.
- UPC
- 781568394953
- Supplier Part Number
- EJMM4109T
- Category
- AC Motors
- Subcategory
- JM,JP,WCP Close Coupled Motors
- Product Family
- General Purpose
- Agency Approvals
- CURUSEEV, NEMA_PREMIUM
- Ambient Temperature
- 40 °C
- Approximate Weight (lbs)
- 487.0
- Auxillary Box
- No Auxillary Box
- Auxillary Box Lead Termination
- None
- Base Indicator
- Rigid
- Bearing Grease Type
- Polyrex EM (-20F +300F)
- Blower
- None
- Catalog Number
- EJMM4109T
- Current @ Voltage
- 45.000 A @ 460.0 V, 90.000 A @ 230.0 V, 100.000 A @ 208.0 V
- Design Code
- A
- Drip Cover
- No Drip Cover
- Duty Rating
- CONT
- Efficiency @ 100% Load
- 92.4 %
- Electrically Isolated Bearing
- Not Electrically Isolated
- Enclosure
- TEFC
- Feedback Device
- NO FEEDBACK
- Frame
- 324JM
- Frame Material
- Cast Iron
- Frequency
- 60.00 Hz
- Front Face Code
- Standard
- Front Shaft Indicator
- None
- Haz Area Class and Group
- NONE
- Haz Area Division
- Not Applicable
- Heater Indicator
- No Heater
- High Voltage Full Load Amps
- 45.0 a
- Insulation Class
- F
- Inverter Code
- Inverter Ready
- KVA Code
- H
- Lifting Lugs
- Standard Lifting Lugs
- Locked Bearing Indicator
- Locked Bearing
- Motor Lead Exit
- Ko Box
- Motor Lead Quantity/Wire Size
- 9 @ 8 AWG
- Motor Lead Termination
- Flying Leads
- Motor Letter Type
- Three Phase
- Motor Standards
- NEMA
- Motor Type
- 1058M
- Mounting Arrangement
- F1
- Number of Poles
- 2
- Output
- 40.000 hp
- Output @ Frequency
- 40.000 HP @ 60 HZ
- Overall Length
- 30.69 IN
- Phase
- 3
- Power Factor
- 90
- Pulley End Bearing Type
- Ball
- Pulley Face Code
- C-Face
- Pulley Shaft Indicator
- Tapped & Key
- Rodent Screen
- None
- Service Factor
- 1.15
- Shaft Diameter
- 1.250 IN
- Shaft Extension Location
- Pulley End
- Shaft Ground Indicator
- No Shaft Grounding
- Shaft Rotation
- Reversible
- Shaft Slinger Indicator
- Shaft Slinger
- Speed
- 3530 rpm
- Speed Code
- Single Speed
- Starting Method
- Direct on line
- Synchronous Speed
- 3,600 rpm
- Synchronous Speed @ Frequency
- 3600 RPM @ 60 HZ
- Thermal Device - Bearing
- None
- Thermal Device - Winding
- None
- Vibration Sensor Indicator
- No Vibration Sensor
- Voltage
- 230 V, 460 V
- Voltage @ Frequency
- 460.0 V @ 60 HZ, 230.0 V @ 60 HZ
- Winding Thermal 1
- None
- Winding Thermal 2
- None
