Image shown may not be actual product
Roll over image to zoom in
Click on image to zoom
Description
Baldor Replacement Part — Component
The Baldor D5005P for Baldor pump systems.
Part Specifications
| Part Number | D5005P |
| Brand | Baldor |
⚠ Confirm Compatibility Before OrderingAlways verify this part is correct for your specific pump model. Contact PumpStop with your pump model number and we'll confirm.
- UPC
- 781568125182
- Supplier Part Number
- D5005P
- Category
- DC Motors
- Subcategory
- Round Frame Motors
- Agency Approvals
- CSA
- Ambient Temperature
- 40 °C
- Approximate Weight (lbs)
- 162.0
- Armature Current
- 8.5 a
- Armature Voltage
- 500 V
- Base Indicator
- Rigid
- Base Speed
- 1,750 rpm
- Bearing Grease Type
- No Grease
- Drip Cover
- No Drip Cover
- Duty Rating
- CONT
- Enclosure
- DPFG
- Feedback Device
- NO FEEDBACK
- Field Voltage
- 300 V, 150 V
- Field Winding Type
- STR. SHUNT
- Frame
- 186AT
- Frame Material
- Steel
- Heater Indicator
- No Heater
- Insulation Class
- F
- Lifting Lugs
- Standard Lifting Lugs
- Motor Standards
- NEMA
- Mounting Arrangement
- F3
- Output Power
- 5 hp
- Overall Length
- 20.87 IN
- Service Factor
- 1
- Shaft Diameter
- 1.125 IN
- Shaft Extension Location
- Pulley End
- Shaft Ground Indicator
- No Shaft Grounding
- Shaft Slinger Indicator
- No Slinger
- Thermal Device - Bearing
- None
