Baldor CSPM3545 - 1 HP, 3450RPM, 3 Phase, 60HZ, 56HC, 3516M, TEFC, F1 60HZ Three Phase 1 HP 3516 M Cable

Save $478.80
BaldorSKU: CSPM3545

Price:
Sale price$718.20 Regular price$1,197.00
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Baldor CSPM3545 - 1 HP General Unit Handling Motor

The Baldor CSPM3545 is a high-performance 1 HP, 3450 RPM, three-phase motor designed for general unit handling applications. With a robust TEFC (Totally Enclosed Fan Cooled) design, this motor ensures durability and reliability in various industrial settings. Operating at 60Hz, it features a 56HC frame and is ideal for those seeking efficient and powerful motor solutions.

Key Specifications:

  • Power: 1 HP
  • Speed: 3450 RPM
  • Phase: 3 Phase
  • Frequency: 60Hz
  • Frame: 56HC
  • Model: 3516M
  • Type: TEFC
  • Product Code: CSPM3545

At Pump-Stop, we are your preferred source for replacement pumps and parts. If you have questions or need assistance finding the right pump for your application, please call us at (781) 281-8905. We recommend checking your current pump for the exact part number or SKU that matches the Baldor CSPM3545 to ensure compatibility. If you encounter any difficulties, our team is here to help you find the perfect solution.

UPC 781568761823
Supplier Part Number CSPM3545
Category AC Motors
Subcategory General Unit Handling Motors
Product Family General Purpose
Agency Approvals C UR US
Ambient Temperature 40 °C
Approximate Weight (lbs) 50.0
Auxillary Box No Auxillary Box
Auxillary Box Lead Termination None
Base Indicator Rigid
Bearing Grease Type Polyrex EM (-20F +300F)
Blower None
Catalog Number CSPM3545
Current @ Voltage 1.300 A @ 460.0 V, 2.600 A @ 230.0 V
Design Code B
Drip Cover No Drip Cover
Duty Rating CONT
Efficiency @ 100% Load 82.0 %
Electrically Isolated Bearing Not Electrically Isolated
Enclosure TEFC
Feedback Device NO FEEDBACK
Frame 56C
Frame Material Steel
Frequency 60.00 Hz
Front Face Code Standard
Front Shaft Indicator None
Haz Area Class and Group NONE
Haz Area Division Not Applicable
Heater Indicator No Heater
High Voltage Full Load Amps 1.3 a
Insulation Class F
Inverter Code Inverter Ready
KVA Code J
Lifting Lugs No Lifting Lugs
Locked Bearing Indicator Locked Bearing
Motor Lead Exit Ko Box
Motor Lead Termination Flying Leads
Motor Letter Type Brushless Wound Field PM Rotor
Motor Standards NEMA
Motor Type 3520B
Mounting Arrangement F3
Number of Poles 2
Output 1.000 hp
Output @ Frequency 1.000 HP @ 60 HZ
Overall Length 12.23 IN
Phase 3
Power Factor 88
Pulley End Bearing Type Ball
Pulley Face Code C-Face
Pulley Shaft Indicator Standard
Rodent Screen None
Service Factor 1
Shaft Extension Location Pulley End
Shaft Ground Indicator No Shaft Grounding
Shaft Rotation Reversible
Shaft Slinger Indicator No Slinger
Speed 3600 rpm
Speed Code Single Speed
Starting Method Direct on line
Synchronous Speed 3,600 rpm
Synchronous Speed @ Frequency 3600 RPM @ 60 HZ
Thermal Device - Bearing None
Thermal Device - Winding None
Vibration Sensor Indicator No Vibration Sensor
Voltage 230 V, 460 V
Voltage @ Frequency 230.0 V @ 60 HZ, 460.0 V @ 60 HZ
Winding Thermal 1 None
Winding Thermal 2 None
