Baldor CESWDM3611T - 3 HP, 1760RPM, 3 Phase, 60HZ, 182TC, 3632M, TEFC, F1 60HZ Three Phase 3 HP 3632 M Cable

Save $1,191.60
BaldorSKU: CESWDM3611T

Price:
Sale price$1,787.40 Regular price$2,979.00
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Baldor CESWDM3611T - 3 HP Paint Free Motor

Upgrade your pumping system with the Baldor CESWDM3611T, a high-performance 3 HP motor designed for efficiency and durability. Operating at 1760 RPM, this three-phase motor is perfect for a variety of industrial applications. With a 60Hz frequency and a 182TC frame size, it ensures reliable performance in demanding environments.

This TEFC (Totally Enclosed Fan Cooled) motor is built to withstand harsh conditions while providing optimal cooling and protection. The paint-free design makes it ideal for applications where cleanliness is a priority.

At Pump-Stop.com, we are your preferred source for replacement pumps and parts. If you have questions or need assistance finding the right pump for your application, don’t hesitate to call us at (781) 281-8905. We recommend checking your current pump for the exact part number or SKU that matches the Baldor CESWDM3611T to ensure compatibility.

Explore our extensive range of AC Motors, Baldor-Reliance Motors & Drives, and Paint Free Motors to find the perfect solution for your needs.

UPC 781568490921
Supplier Part Number CESWDM3611T
Category AC Motors
Subcategory Paint Free Motors
Product Family Wash Down Paint Free
Agency Approvals NEMA_PREMIUM, CURUSEEV, CURUS
Ambient Temperature 40 °C
Approximate Weight (lbs) 79.0
Auxillary Box No Auxillary Box
Auxillary Box Lead Termination None
Base Indicator Rigid
Bearing Grease Type Polyrex EM (-20F +300F)
Blower None
Catalog Number CESWDM3611T
Current @ Voltage 4.000 A @ 460.0 V, 8.000 A @ 230.0 V, 8.100 A @ 208.0 V
Design Code B
Drip Cover No Drip Cover
Duty Rating CONT
Efficiency @ 100% Load 89.5 %
Electrically Isolated Bearing Not Electrically Isolated
Enclosure TEFC
Feedback Device NO FEEDBACK
Frame 182TC
Frame Material Stainless Steel
Frequency 60.00 Hz
Front Face Code Standard
Front Shaft Indicator None
Haz Area Class and Group NONE
Haz Area Division Not Applicable
Heater Indicator No Heater
High Voltage Full Load Amps 4.0 a
Insulation Class F
Inverter Code Inverter Ready
KVA Code K
Lifting Lugs No Lifting Lugs
Locked Bearing Indicator Locked Bearing
Motor Lead Exit Ko Box
Motor Lead Quantity/Wire Size 9 @ 16 AWG
Motor Lead Termination Flying Leads
Motor Letter Type Three Phase
Motor Standards NEMA
Motor Type 3632M
Mounting Arrangement F1
Number of Poles 4
Output 3.000 hp
Output @ Frequency 3.000 HP @ 60 HZ
Overall Length 16.50 IN
Phase 3
Power Factor 78
Pulley End Bearing Type Ball
Pulley Face Code C-Face
Pulley Shaft Indicator Standard
Rodent Screen None
Service Factor 1.15
Shaft Diameter 1.125 IN
Shaft Extension Location Pulley End
Shaft Ground Indicator No Shaft Grounding
Shaft Rotation Reversible
Shaft Slinger Indicator Shaft Slinger
Speed 1760 rpm
Speed Code Single Speed
Starting Method Direct on line
Synchronous Speed 1,800 rpm
Synchronous Speed @ Frequency 1800 RPM @ 60 HZ
Thermal Device - Bearing None
Thermal Device - Winding None
Vibration Sensor Indicator No Vibration Sensor
Voltage 460 V, 230 V
Voltage @ Frequency 230.0 V @ 60 HZ, 460.0 V @ 60 HZ
Winding Thermal 1 None
Winding Thermal 2 None
