Baldor CESWDM3558 - 2 HP, 1760RPM, 3 Phase, 60HZ, 56C, 3528M, TEFC, F1, N 60HZ Three Phase 2 HP 3528 M Cable 56°C

Save $914.80
BaldorSKU: CESWDM3558

Price:
Sale price$1,372.20 Regular price$2,287.00
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Baldor CESWDM3558 - 2 HP Paint Free Motor

Upgrade your pumping system with the Baldor CESWDM3558, a high-performance 2 HP, 1760 RPM, 3-phase motor designed for reliability and efficiency. This TEFC (Totally Enclosed Fan Cooled) motor operates at 60Hz and is built to withstand demanding environments, making it an ideal choice for various industrial applications.

Key Features:

  • Power: 2 HP
  • Speed: 1760 RPM
  • Phase: 3 Phase
  • Frequency: 60Hz
  • Frame Size: 56C
  • Design: TEFC (Totally Enclosed Fan Cooled)
  • Product Code: CESWDM3558

This motor is part of the Baldor-Reliance Paint Free Motors series, ensuring a clean and efficient operation without the hassle of paint finishes. Perfect for those looking to replace or upgrade their existing pump motors, the Baldor CESWDM3558 is a trusted choice for performance and durability.

At Pump-Stop.com, we are your preferred source for replacement pumps and parts. If you have questions or need assistance finding the right pump for your application, please call us at (781) 281-8905. We recommend checking your current pump for the exact part number or SKU that matches the Baldor CESWDM3558, and don’t hesitate to reach out if you need help locating the right item.

UPC 781568778456
Supplier Part Number CESWDM3558
Category AC Motors
Subcategory Paint Free Motors
Product Family Wash Down Paint Free
Agency Approvals NEMA_PREMIUM, CURUSEEV
Ambient Temperature 40 °C
Approximate Weight (lbs) 45.0
Auxillary Box No Auxillary Box
Auxillary Box Lead Termination None
Base Indicator Rigid
Bearing Grease Type Polyrex EM (-20F +300F)
Blower None
Catalog Number CESWDM3558
Current @ Voltage 2.800 A @ 460.0 V, 5.600 A @ 230.0 V, 5.800 A @ 208.0 V
Design Code B
Drip Cover No Drip Cover
Duty Rating CONT
Efficiency @ 100% Load 86.5 %
Electrically Isolated Bearing Not Electrically Isolated
Enclosure TEFC
Feedback Device NO FEEDBACK
Frame 56C
Frame Material Stainless Steel
Frequency 60.00 Hz
Front Shaft Indicator None
Haz Area Class and Group NONE
Haz Area Division Not Applicable
Heater Indicator No Heater
High Voltage Full Load Amps 2.8 a
Insulation Class F
Inverter Code Inverter Ready
KVA Code K
Lifting Lugs No Lifting Lugs
Locked Bearing Indicator Locked Bearing
Motor Lead Quantity/Wire Size 9 @ 18 AWG
Motor Lead Termination Flying Leads
Motor Letter Type Three Phase
Motor Standards NEMA
Motor Type 3528M
Mounting Arrangement F1
Number of Poles 4
Output 2.000 hp
Output @ Frequency 2.000 HP @ 60 HZ
Overall Length 13.24 IN
Phase 3
Power Factor 77
Pulley End Bearing Type Sealed Bearing
Pulley Face Code C-Face
Pulley Shaft Indicator Standard
Rodent Screen None
Service Factor 1.15
Shaft Diameter 0.625 IN
Shaft Ground Indicator No Shaft Grounding
Shaft Rotation Reversible
Shaft Slinger Indicator Shaft Slinger
Speed 1760 rpm
Speed Code Single Speed
Starting Method Direct on line
Synchronous Speed 1,800 rpm
Synchronous Speed @ Frequency 1800 RPM @ 60 HZ
Thermal Device - Bearing None
Thermal Device - Winding None
Vibration Sensor Indicator No Vibration Sensor
Voltage 460 V, 230 V
Voltage @ Frequency 230.0 V @ 60 HZ, 460.0 V @ 60 HZ
Winding Thermal 1 None
Winding Thermal 2 None

Motor Curves
