Baldor CEM7068T-I - 75//60HP, 1780//1480RPM, 3 Phase, 60//50HZ, 365T 50HZ Three Phase 60 HP

Save $6,363.60
BaldorSKU: CEM7068T-I

Price:
Sale price$9,545.40 Regular price$15,909.00
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Baldor-Reliance Explosion Proof Drill Rig Duty Motor - CEM7068T-I

Introducing the Baldor-Reliance Explosion Proof Drill Rig Duty Motor, a robust and reliable solution designed for demanding applications. This motor features a power rating of 75/60 HP and operates at speeds of 1780/1480 RPM, making it ideal for various industrial uses. With a three-phase design and compatibility with both 60Hz and 50Hz power supplies, this motor is versatile and efficient.

Specifications:

  • Power: 75/60 HP
  • Speed: 1780/1480 RPM
  • Phase: 3 Phase
  • Frequency: 60/50 Hz
  • Frame Size: 365T
  • Product Code: CEM7068T-I

This explosion-proof motor is specifically designed for drill rig applications, ensuring safety and performance in hazardous environments. At Pump-Stop, we pride ourselves on being the preferred source for replacement pumps and parts, including high-quality motors like the Baldor CEM7068T-I.

If you have questions or need assistance in finding the right pump for your application, please call us at (781) 281-8905. We recommend checking your current pump for the exact part number or SKU to ensure compatibility. Our team is here to help you find the perfect solution for your needs.

UPC 781568726068
Supplier Part Number CEM7068T-I
Category AC Motors
Subcategory Explosion Proof Drill Rig Duty Motors
Product Family General Industrial
Agency Approvals UL, CURUSEEV, CSA, CCSAUSEEV
Ambient Temperature 40 °C
Approximate Weight (lbs) 977.0
Auxillary Box No Auxillary Box
Base Indicator Rigid
Bearing Grease Type Polyrex EM (-20F +300F)
Catalog Number CEM7068T-I
Current @ Voltage 84.100 A @ 460.0 V, 82.000 A @ 380.0 V, 168.000 A @ 230.0 V, 164.000 A @ 190.0 V
Design Code B
Drip Cover No Drip Cover
Duty Rating CONT
Efficiency @ 100% Load 95.4 %
Enclosure TEFC
Feedback Device NO FEEDBACK
Frame 365TC
Frame Material Cast Iron
Frequency 50.00 Hz, 60.00 Hz
Haz Area Class and Group Class I, Group C & D
Haz Area Division Division I
Haz Area Temp Code T3C
Heater Indicator No Heater
High Voltage Full Load Amps 82.0 a
Insulation Class F
Inverter Code Not Inverter
KVA Code F
Lifting Lugs Standard Lifting Lugs
Motor Lead Quantity/Wire Size 3 @ 4 AWG
Motor Letter Type Three Phase
Motor Standards NEMA
Motor Type A36068M
Mounting Arrangement F1
Number of Poles 4
Output 60.000 hp @ 50 Hz, 75.000 hp @ 60 Hz
Output @ Frequency 60.000 HP @ 50 HZ, 75.000 HP @ 60 HZ
Overall Length 33.44 IN
Phase 3
Power Factor 88
Pulley End Bearing Type Ball
Pulley Face Code C-Face
Service Factor 1.15
Shaft Diameter 2.374 IN
Shaft Ground Indicator No Shaft Grounding
Shaft Rotation Reversible
Shaft Slinger Indicator No Slinger
Speed 1480 rpm, 1780 rpm
Speed Code Single Speed
Starting Method Direct on line
Synchronous Speed 1,800 rpm
Synchronous Speed @ Frequency 1800 RPM @ 60 HZ
Thermal Device - Bearing None
Thermal Device - Winding Normally Closed Thermostat
Voltage 190 V @ 50 Hz, 380 V @ 50 Hz, 230 V @ 60 Hz, 460 V @ 60 Hz
Voltage @ Frequency 230.0 V @ 60 HZ, 190.0 V @ 50 HZ, 460.0 V @ 60 HZ, 380.0 V @ 50 HZ

Motor Curves
