Image shown may not be actual product
Roll over image to zoom in
Click on image to zoom
Description
Baldor Replacement Part — Component
The Baldor CECP4312T for Baldor pump systems.
Part Specifications
| Part Number | CECP4312T |
| Brand | Baldor |
⚠ Confirm Compatibility Before OrderingAlways verify this part is correct for your specific pump model. Contact PumpStop with your pump model number and we'll confirm.
- UPC
- 781568726020
- Supplier Part Number
- CECP4312T
- Category
- AC Motors
- Subcategory
- Severe Duty XEX Motors
- Product Family
- General Industrial
- Agency Approvals
- CCSAUSEEV, CURUSEEV, NEMA_PREMIUM, UR
- Ambient Temperature
- 40 °C
- Approximate Weight (lbs)
- 908.0
- Auxillary Box
- No Auxillary Box
- Base Indicator
- Rigid
- Bearing Grease Type
- Polyrex EM (-20F +300F)
- Catalog Number
- CECP4312T
- Constant Torque Speed Range
- 6-60
- Current @ Voltage
- 61.700 A @ 460.0 V, 135.000 A @ 208.0 V, 123.000 A @ 230.0 V
- Design Code
- B
- Drip Cover
- No Drip Cover
- Duty Rating
- CONT
- Efficiency @ 100% Load
- 94.1 %
- Enclosure
- TEFC
- Feedback Device
- NO FEEDBACK
- Frame
- 365TC
- Frame Material
- Cast Iron
- Frequency
- 60.00 Hz
- Haz Area Class and Group
- Class I, Group A,B,C & D
- Haz Area Division
- Division II
- Haz Area Temp Code
- T3A
- Heater Indicator
- No Heater
- High Voltage Full Load Amps
- 61.7 a
- Insulation Class
- F
- Inverter Code
- Inverter Ready
- KVA Code
- F
- Lifting Lugs
- Standard Lifting Lugs
- Max Speed
- 1800 rpm
- Motor Lead Quantity/Wire Size
- 3 @ 4 AWG
- Motor Letter Type
- Three Phase
- Motor Standards
- NEMA
- Motor Type
- A36062M
- Mounting Arrangement
- F1
- Number of Poles
- 6
- Output
- 50.000 hp
- Output @ Frequency
- 50.000 HP @ 60 HZ
- Overall Length
- 33.44 IN
- Phase
- 3
- Power Factor
- 81
- Pulley End Bearing Type
- Ball
- Pulley Face Code
- C-Face
- Service Factor
- 1.15
- Shaft Diameter
- 2.375 IN
- Shaft Ground Indicator
- No Shaft Grounding
- Shaft Rotation
- Reversible
- Shaft Slinger Indicator
- Shaft Slinger
- Speed
- 1185 rpm
- Speed Code
- Single Speed
- Starting Method
- Direct on line
- Synchronous Speed
- 1,200 rpm
- Synchronous Speed @ Frequency
- 1200 RPM @ 60 HZ
- Thermal Device - Bearing
- None
- Thermal Device - Winding
- None
- Voltage
- 230 V, 460 V
- Voltage @ Frequency
- 230.0 V @ 60 HZ, 460.0 V @ 60 HZ
