UPC
781568924303
Supplier Part Number
CDRX050744
Category
AC Motors
Subcategory
Explosion Proof Drill Rig Duty Motors
Product Family
General Purpose
Agency Approvals
CSA, UL
Ambient Temperature
40 °C
Approximate Weight (lbs)
33.0
Auxillary Box
No Auxillary Box
Auxillary Box Lead Termination
None
Base Indicator
Rigid
Bearing Grease Type
Polyrex EM (-20F +300F)
Blower
None
Catalog Number
CDRX050744
Constant Torque Speed Range
6
Current @ Voltage
2.400 A @ 230.0 V, 2.400 A @ 208.0 V, 2.200 A @ 190.0 V, 1.200 A @ 460.0 V, 1.100 A @ 380.0 V
Design Code
B
Drip Cover
No Drip Cover
Duty Rating
CONT
Efficiency @ 100% Load
82.5 %
Electrically Isolated Bearing
Not Electrically Isolated
Enclosure
TEFC
Feedback Device
NO FEEDBACK
Frame
56C
Frame Material
Steel
Frequency
50.00 Hz, 60.00 Hz
Haz Area Class and Group
Class I, Group C & D
Haz Area Division
Division I
Haz Area Temp Code
T3C
Heater Indicator
No Heater
High Voltage Full Load Amps
1.1 a
Insulation Class
F
Inverter Code
Inverter Duty
IP Rating
NONE
KVA Code
K
Lifting Lugs
No Lifting Lugs
Locked Bearing Indicator
Locked Bearing
Max Speed
2700 rpm
Motor Lead Termination
Flying Leads
Motor Letter Type
Three Phase
Motor Standards
NEMA
Motor Type
3514M
Mounting Arrangement
F1
Number of Poles
4
Output
0.500 hp @ 50 Hz, 0.750 hp @ 60 Hz
Output @ Frequency
.500 HP @ 50 HZ, .750 HP @ 60 HZ
Overall Length
14.28 IN
Phase
3
Power Factor
74
Pulley Face Code
C-Face
Rodent Screen
None
RoHS Status
ROHS NON-COMPLIANT
Service Factor
1
Shaft Diameter
0.625 IN
Shaft Ground Indicator
No Shaft Grounding
Shaft Rotation
Reversible
Speed
1765 rpm
Speed Code
Single Speed
Starting Method
Direct on line
Synchronous Speed
1,800 rpm
Synchronous Speed @ Frequency
1800 RPM @ 50 HZ
Thermal Device - Bearing
None
Thermal Device - Winding
Normally Closed Thermostat
Vibration Sensor Indicator
No Vibration Sensor
Voltage
190 V @ 50 Hz, 380 V @ 50 Hz, 230 V @ 60 Hz, 460 V @ 60 Hz
Voltage @ Frequency
380.0 V @ 50 HZ, 230.0 V @ 60 HZ, 190.0 V @ 50 HZ, 460.0 V @ 60 HZ
Winding Thermal 1
None
Winding Thermal 2
None
