Baldor AFL3520A - .75 HP, 3450RPM, 1 Phase, 60HZ, 56Z, 3420L, Teao, F1 60HZ Single Phase 75 HP

Save $262.80
BaldorSKU: AFL3520A

Price:
Sale price$394.20 Regular price$657.00
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Baldor AFL3520A Application Specific Motor

Upgrade your pumping system with the Baldor AFL3520A, a high-performance application specific motor designed for reliability and efficiency. This motor features a robust .75 HP power output and operates at 3450 RPM, making it ideal for various pumping applications.

Key specifications include:

  • Phase: 1 Phase
  • Frequency: 60HZ
  • Frame Size: 56Z
  • Enclosure Type: TEAO (Totally Enclosed Air Over)
  • Product Code: AFL3520A

As a trusted vendor, Baldor ensures that this motor meets the highest standards of quality and performance, making it a perfect choice for your specific needs.

At Pump-Stop.com, we are your preferred source for replacement pumps and parts. If you have questions or need assistance finding the right pump for your application, please call us at (781) 281-8905. We recommend checking your current pump for the exact part number or SKU that matches the Baldor AFL3520A to ensure compatibility. Don’t hesitate to reach out if you need help locating the right item!

UPC 781568121283
Supplier Part Number AFL3520A
Category AC Motors
Subcategory Application Specific Motors
Product Family General Purpose
Agency Approvals UR, CURUS, CSA
Ambient Temperature 40 °C
Approximate Weight (lbs) 29.0
Auxillary Box No Auxillary Box
Auxillary Box Lead Termination None
Base Indicator Rigid
Bearing Grease Type Polyrex EM (-20F +300F)
Blower None
Catalog Number AFL3520A
Current @ Voltage 11.000 A @ 115.0 V, 5.500 A @ 230.0 V
Design Code N
Drip Cover No Drip Cover
Duty Rating CONT
Efficiency @ 100% Load 71.0 %
Electrically Isolated Bearing Not Electrically Isolated
Enclosure TEAO
Feedback Device NO FEEDBACK
Frame 56Z
Frame Material Steel
Frequency 60.00 Hz
Front Face Code Terminal Panel
Front Shaft Indicator None
Haz Area Class and Group NONE
Haz Area Division Not Applicable
Heater Indicator No Heater
High Voltage Full Load Amps 5.5 a
Insulation Class B
Inverter Code Not Inverter
KVA Code J
Lifting Lugs No Lifting Lugs
Locked Bearing Indicator No Locked Bearing
Motor Lead Exit Lead Hole
Motor Lead Quantity/Wire Size 6 @ 18 AWG
Motor Lead Termination Cord And Plug
Motor Letter Type Cap Start, Induction Run
Motor Standards NEMA
Motor Type 3420L
Mounting Arrangement F1
Number of Poles 2
Output 0.750 hp
Output @ Frequency .750 HP @ 60 HZ
Overall Length 11.59 IN
Phase 1
Power Factor 68
Product Type FARM DUTY
Pulley End Bearing Type Sealed Bearing
Pulley Face Code Standard
Pulley Shaft Indicator Tapped & Key
Rodent Screen None
Service Factor 1
Shaft Diameter 0.625 IN
Shaft Extension Location Pulley End
Shaft Ground Indicator No Shaft Grounding
Shaft Rotation Reversible: Connected Standard
Shaft Slinger Indicator No Slinger
Speed 3450 rpm
Speed Code Single Speed
Starting Method Direct on line
Synchronous Speed 3,600 rpm
Synchronous Speed @ Frequency 3600 RPM @ 60 HZ
Thermal Device - Bearing None
Thermal Device - Winding None
Vibration Sensor Indicator No Vibration Sensor
Voltage 115 V, 230 V
Voltage @ Frequency 115.0 V @ 60 HZ, 230.0 V @ 60 HZ
Winding Thermal 1 Automatic Thermal Overload
Winding Thermal 1 Location SB
Winding Thermal 2 None
