Description
The Lutz 0060-002 is a Pump Motor, electric motor-driven, 230V / 50Hz.
Matched to Lutz Pump Tube Assemblies
Lutz motors are designed specifically for use with Lutz pump tube assemblies. The shaft connection, speed, and power output are matched to the pump tube hydraulic requirements. Verify model compatibility before ordering.
IP Protection for Chemical Environments
Motor protection class IP24 or IP54 provides splash and dust protection required in industrial chemical drum transfer environments where motor exposure to mist and drips is unavoidable during normal operation.
ATEX Explosion-Protected Options
ATEX-rated explosion-proof motors are available for hazardous area classifications — required when pumping flammable solvents, fuels, or other ignitable liquids in Zone 1 or Zone 2 classified locations.
Variable Speed Version — B2 Vario
The Lutz B2 Vario motor provides variable speed control for adjustable flow rates — critical for controlled dispensing and filling operations where a fixed flow rate would cause overfill or splashing.
| Part Number | 0060-002 |
| Product Type | Pump Motor |
| Product Name | Motor MA II 7 |
| Drive Type | Electric Motor |
| Voltage | 230V |
| Frequency | 50 Hz |
| Power | 795W |
| Protection Class | IP54 |
| Configuration | ohne Unterspannungsauslöser |
| Type / Model Code | MA II 7-230 |
| Chemical compatibility | Always verify pump tube, impeller, and seal materials are compatible with your specific fluid, concentration, and temperature before installation. |
| Electrical safety | Requires a properly earthed 230V supply. Never connect to a different voltage. Protect motor with a correctly rated circuit breaker. |
| Explosion protection | Standard version is not explosion protected. For flammable fluids or hazardous locations, specify an ATEX-rated version. |
| Drum fit | Ensure the drum bung opening is compatible with the pump tube diameter before installation. The pump tube must not exceed the bung opening to ensure a leak-free, gas-tight connection. |
