Washdown Duty Motor, 0.33 HP, 1800 RPM, 230/460V, 56C Frame, C-Face Round Body, Tenv Enclosure 460V 60HZ Three Phase 5 HP Stainless Steel 56°C

WorldWide ElectricSKU: WSSNV13-18-56CRD

Price:
Sale price$205.55
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

WorldWide Electric Washdown Duty Motor - 0.33 HP

Introducing the WorldWide Electric Washdown Duty Motor, a reliable and efficient solution for your industrial applications. This motor features a robust 0.33 HP output, operating at 1800 RPM, and is designed for three-phase power with a voltage rating of 230/460V. Its 56C frame and C-face round body design ensure easy installation and compatibility with various mounting configurations.

Constructed with a stainless steel housing, this motor is specifically engineered for washdown environments, providing superior resistance to moisture and corrosion. The TENV (Totally Enclosed Non-Ventilated) enclosure further enhances its durability, making it ideal for demanding applications in food processing, pharmaceuticals, and other industries where hygiene is paramount.

With a standard efficiency rating and a service factor of 1.15, this motor delivers reliable performance while maintaining energy efficiency. Whether you need a replacement or an upgrade, the WorldWide Electric Washdown Duty Motor is the perfect choice.

At Pump-Stop.com, we are your preferred source for replacement pumps and parts. If you have questions or need assistance finding the right pump for your application, please call us at (781) 281-8905. We recommend checking your current pump for the exact part number or SKU that matches this motor, and don’t hesitate to reach out if you need help locating the right item.

Specifications:

  • Power: 0.33 HP
  • Speed: 1800 RPM
  • Voltage: 230/460V
  • Frame: 56C
  • Type: C-Face Round Body
  • Enclosure: TENV
  • Application: Washdown Duty
  • Material: Stainless Steel

Upgrade your operations with the WorldWide Electric Washdown Duty Motor today!

Category Electric Motors
Subcategory Stainless Steel / Washdown Duty Motors
Approximate Weight (lbs) 28
Degree of Protection IP56
Enclosure Type TENV
FL Efficiency (%) 82.5
Frame Size 56C
Frequency 60/50 HZ*
Full Load Amps 0.7
Horsepower 0.33
Insulation Class Class F
Mounting Type C-Face Round Body (Footless)
Phase Three-Phase
RPM 1800
Service Factor 1.15
Voltage 230/460

Motor Curves
