VHS-V1 30 HP 1800 RPM 3 Phase 60 HZ 230/460V 1.15 Sf 286TP Frame, Wpi ODP, Vertical Hollow Shaft Motor, Cast Iron, Premium Efficiency, P-Cap Screw Mounting, 16.5 Inch Cap Screw

This item ships free!
WorldWide ElectricSKU: V1-30D4-W28616B

Price:
Sale price$3,129.99
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

WorldWide Electric 30 HP Vertical Hollow Shaft Motor

Introducing the VHS-V1 30 HP Vertical Hollow Shaft Motor from WorldWide Electric, designed for premium efficiency and reliable performance in demanding applications. This 3-phase motor operates at 1800 RPM and is suitable for 60 Hz power supply, with dual voltage options of 230/460V. Featuring a robust cast iron construction, this motor is built to withstand the rigors of industrial environments.

Key specifications include:

  • Power: 30 HP
  • Speed: 1800 RPM
  • Phase: 3 Phase
  • Frequency: 60 Hz
  • Voltage: 230/460V
  • Service Factor: 1.15
  • Frame: 286TP
  • Type: ODP (Open Drip Proof)
  • Mounting: P-Cap Screw Mounting
  • Cap Screw Length: 16.5 Inches

This motor is ideal for various applications, including pumps, fans, and compressors, making it a versatile choice for your operational needs. At Pump-Stop, we are your preferred source for replacement pumps and parts, ensuring you find the right solution for your specific requirements.

For assistance, please check your current pump for the exact part number or SKU that matches this motor. If you have any questions or need help finding the right item, don't hesitate to call us at (781) 281-8905.

Supplier Part Number V1-30D4-W28616B
Degree of Protection IP23
Enclosure Type Weather Protected (WPI)
Frame Size 286TP
Frequency 60 HZ
Horsepower 30
Insulation Class Class F
Mounting Type P-Base
Phase Three-Phase
RPM 1800
Service Factor 1.15
Voltage 230/460
