VHS-V1 10 HP 1800 RPM 3 Phase 60 HZ 230/460V 1.15 Sf 215TP Frame, Wpi ODP, Vertical Hollow Shaft Motor, Cast Iron, Premium Efficiency, P-Cap Screw Mounting, 10 Inch Cap Screw

This item ships free!
WorldWide ElectricSKU: V1-10D4-W21510A

Price:
Sale price$2,246.43
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

WorldWide Electric 10 HP Vertical Hollow Shaft Motor

The VHS-V1 10 HP Vertical Hollow Shaft Motor from WorldWide Electric is designed for premium efficiency and reliable performance in demanding applications. With a robust 1800 RPM speed and a 3-phase power supply, this motor operates at 60 Hz and is compatible with both 230V and 460V systems. Its 1.15 service factor ensures optimal performance under varying load conditions.

Constructed from durable cast iron, this motor features a 215TP frame and is equipped with a WPI ODP (Open Drip Proof) design, making it suitable for vertical installations. The P-Cap screw mounting allows for easy installation and maintenance, while the 10-inch cap screw provides added stability.

At Pump-Stop.com, we pride ourselves on being the preferred source for replacement pumps and parts. If you have questions or need assistance finding the right pump for your application, please call us at (781) 281-8905. We recommend checking your current pump for the exact part number or SKU that matches this motor, ensuring a perfect fit for your needs.

Explore our extensive range of electric motors, including special purpose and vertical hollow shaft motors, and experience the quality and reliability that WorldWide Electric is known for.

Supplier Part Number V1-10D4-W21510A
Degree of Protection IP23
Enclosure Type Weather Protected (WPI)
Frame Size 215TP
Frequency 60 HZ
Horsepower 10
Insulation Class Class F
Mounting Type P-Base
Phase Three-Phase
RPM 1800
Service Factor 1.15
Voltage 230/460

Motor Curves
