Description
TP 40-160/2 A-G-Z-BUBE-FY2 | Single-stage centrifugal volute in-line single-head pump: neck rings and impeller made of stainless steel
cataphoresis treatment
shell coupling
top-pull-out principle for easy maintenance
optimized hydraulics
in-line design with opposite suction and discharge ports enabling mounting in pipework or on a concrete foundation
corrosion resistant maintenance-free mechanical shaft seal. The motor is a 3-phase AC motor.
Motor efficiency at full load 1
79.0-80.0 %
Maximum operating pressure
145.04 psi
Power factor 1
0.84-0.78
Rated voltage
3 x 208-230YY/460Y V
KVA code
K
Liquid temperature range
5 .. 284 °F
Insulation class (IEC 85)
F
Motor efficiency at 1/2 load
77.3-75.2 %
Built-in motor protection
NONE
Net weight
67.9 lb
Rated speed
3430-3460 rpm
Gross weight
72.0 lb
Rated power - P2
0.75 HP
Motor efficiency at 3/4 load
79.9-79.3 %
Shaft
Product name:TP 40-160/2 A-G-Z-BUBE-FY2
Rated current
2,40-2,30/1,20 A
Service factor
1.25
Pipe connection
1 1/2"
Full load SF current
2,9-2,75/1,4 A
Motor type
ML71BA, TEFC
Range of ambient temperature
-22 .. 104 °F
Rated flow
59.4 US gpm
Flange standard
USA
Diameter
3.39 in
Approvals on motor nameplate
CE,CURUS,EAC
Housing
Bronze
Rated head
35.76 ft
Actual impeller diameter
3.39 in
Type
ML71BA, TEFC
Curve tolerance
ISO9906:2012 3B2
Primary shaft seal
BUBE
Connection
1 1/2"
Impeller
Stainless steel
Pump housing
Bronze
Standard
USA
Country code
Namreg
Motor Curves
