Description
TP 100-40/4 A-G-A-BUBE-XY4 | Single-stage centrifugal in-line single-head pump. The in-line design with opposite suction and dis-charge ports enables mounting in pipework or ona concrete foundation. The shaft seal is a corrosion-resistantmaintenance-free mechanical seal.
Maximum operating pressure
145.04 psi
Liquid temperature range
5 .. 284 °F
Gross weight
128.0 lb
Shaft
Product name:TP 100-40/4 A-G-A-BUBE-XY4
Pipe connection
4"
Rated flow
181 US gpm
Flange standard
ANSI
Diameter
4.09 in
Housing
Cast iron
Rated head
9.187 ft
Actual impeller diameter
4.09 in
Curve tolerance
ISO 9906:1999 Annex A
Primary shaft seal
BUBE
Connection
4"
Impeller
Stainless steel
Pump housing
Cast iron
Standard
ANSI
Country code
Namreg
Motor Curves
