Description
The Grundfos 96047845 (SEV.80.80.60.2.51D) is a Grundfos Accessory / Spare Part / Control. Genuine Grundfos accessory, control component, spare part, or sensor. Nominal performance: 181US gpm at 56.11ft. Rated 380-415V, 3.0-Phase, 50 Hz. Applications include Plumbing: Sewage, Industrial wastewater treatment & reuse, Municipal wastewater transport and more.
Genuine Grundfos Part
OEM component engineered and manufactured to Grundfos specifications. Maintains pump performance and warranty coverage.
Full Traceability
Genuine Grundfos parts carry manufacturer traceability from production through delivery. No counterfeit risk.
Authorized Source
PumpStop is an authorized Grundfos distributor. All parts are genuine — not aftermarket, not surplus.
Confirm Compatibility
Always verify part number against your pump model number and serial number before ordering. Contact PumpStop for parts identification assistance.
Technical Support Available
PumpStop technical team can identify correct parts from pump nameplate data, serial number, or model code. Call (781) 281-8905 or chat.
Contact for Availability
Parts availability varies. Contact PumpStop to confirm stock, lead time, and pricing before placing an order.
| Model Number | 96047845 |
| Product Series | ACC |
| Series Description | Grundfos Accessory / Spare Part / Control |
| Power | 8HP |
| Voltage | 380-415V |
| Phase | 3.0-Phase |
| Frequency | 50 Hz |
| Motor Speed | 2945rpm |
| Full Load Current | 13.9A |
| Motor Protection | PTO |
| Insulation Class | F |
| Protection Class (IP) | IP68 |
| Nominal Flow | 181US gpm |
| Nominal Head | 56.11ft |
| Max Operating Pressure | 87.02psi |
| Max Fluid Temperature | 104°F |
| Max Ambient Temperature | 104°F |
| Inlet Connection | DN 80 |
| Outlet Connection | DN 80 |
| Pipe Pressure Rating | PN 10 |
| Impeller Material | Cast iron |
| Housing Material | Cast iron |
| Approvals / Certifications | EN12050-1 |
| Electrical | Verify supply voltage, phase, and frequency match nameplate before installation: 380-415V, 3.0-Phase, 50 Hz. |
| Temperature limits | Do not exceed max fluid temperature 104°F or max ambient temperature 104°F. Exceeding limits damages seals and motor insulation. |
| Dry running | Do not run dry. ACC pumps use the pumped fluid to lubricate the shaft seal. Dry running destroys the seal within seconds. Install dry-run protection on all automatic installations. |
| Maintenance | Refer to the Grundfos Installation and Operating Manual (IOM) for correct installation, commissioning, and maintenance. Contact PumpStop for documentation. |
- EAN
- 5700395071399
- Approvals
- EN12050-1
- Approvals and markings
- 27.9 m
- Auto-coupling
- 96090993
- Battery back-up
- 27.9 m
- Breakdown torque
- 112 Nm
- Built-in motor protection
- THERMAL SWITCH
- Cable type
- LYNIFLEX
- Colour
- 27.9 m
- Connect code
- 0.58
- Control box
- not included
- Cos phi - p.f. at 1/2 load
- 0.58
- Cos phi - p.f. at 3/4 load
- 0.7
- Curve tolerance
- ISO9906:2012 3B2
- Density
- 62.29 lb/ft³
- Enclosure class (IEC 34-5)
- IP68
- Explosion proof
- no
- Flange standard
- DIN
- Flow range
- 27.9 m
- Gross weight
- 389.0 lb
- Head max
- 27.9 m
- Housing
- Cast iron
- Impeller
- Cast iron
- Inst dry/wet
- DRY/SUBMERGED
- Insulation class (IEC 85)
- F
- Length
- 27.9 m
- Length of cable
- 10 m
- Liquid temperature range
- 32 .. 104 °F
- Locked-rotor torque
- 80 Nm
- Mains frequency
- 50 Hz
- Max flow
- 25 l/s
- Max starts per hour
- 20
- Maximum ambient temperature
- 104 °F
- Maximum current consumption
- 0.58
- Maximum installation depth
- 7 m
- Maximum operating pressure
- 6 bar
- Maximum particle size
- 80 mm
- Moisture sensor
- without moisture sensors
- Moment of inertia
- 0.451 lb ft²
- Motor
- 27.9 m
- Motor efficiency at 1/2 load
- 0.775
- Motor efficiency at 3/4 load
- 0.822
- Motor efficiency at full load 1
- 0.841
- Net weight
- 343.0 lb
- Number of leads
- 27.9 m
- Number of poles
- 2
- Pipework connection
- 27.9 m
- Power 1
- 7.1 kW
- Power factor 1
- 0.78
- Power input - P1
- 7.1 kW
- Pressure rating
- PN 10
- Pressure retention valve
- 27.9 m
- Primary shaft seal
- SIC/SIC
- Pump housing
- Cast iron
- Pump inlet
- 0.58
- Pump outlet
- DN 80
- Rated current
- 13.7-14.2 A
- Rated current at 1/2 load
- 9.7 A
- Rated current at 3/4 load
- 11.3 A
- Rated current at no load
- 7.8 A
- Rated power - P2
- 6 kW
- Rated speed
- 2945 rpm
- Rated voltage
- 3 x 380-415 V
- Real Time
- Delivery date to be confirmed on Sales Order Update with real time availability and Net price
- Sens.interface
- 27.9 m
- Size
- 80 mm
- Standard
- DIN
- Start. method
- star/delta
- Starting current
- 148 A
- Temp. sensor
- N
- Thermal protec
- internal
- Type
- LYNIFLEX
- Type of cable plug
- No plug
- Type of impeller
- SUPER VORTEX
- Valve type
- 27.9 m
- Voltage tolerance
- +6/-10 %
- Water-in-oil sensor
- without water-in-oil sensor
