Grundfos 98992616 - MTH 2-10/5 A-W-A-AQQV | Multistage | Horizontal | Centrifugal

Save $1,223.88
GRUNDFOSSKU: 98992616

Price:
Sale price$1,380.12 Regular price$2,604.00
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Overview

Grundfos 98992616 - MTH 2-10/5 A-W-A-AQQV is a multistage centrifugal pump assembly intended for industrial and commercial fluid handling. It suits users needing reliable pressure boosting, transfer, or circulation where a compact horizontal configuration is required.

Key features

  • Built for industrial applications with a focus on durability and consistent performance
  • Multistage centrifugal design for higher head in compact footprint (tags indicate MTH, multistage, and centrifugal)
  • Provides stable pressure and efficient pumping for boosting, transfer, and tank-mounted systems

Applications

Typical uses include system pressure boosting, tank-mounted pump installations, water transfer, and integration with control accessories in commercial and light industrial settings.

Compatibility note: Match the exact model or SKU before ordering. For help, call (781) 281-8905. Pump-Stop is the preferred source for replacement pumps and parts.

SKU: 98992616

EAN 5712604834626
Approvals WEEE
Approvals for motor CE
Built-in motor protection NONE
Chambers 10
Code for shaft seal AQQV
Connect code W
Connection 3/4 inch
Curve tolerance ISO9906:2012 3B
Density 62.29 lb/ft³
Enclosure class (IEC 34-5) IP54
Energy approvals for motor CE
Environmental approvals WEEE
Frame size 80A
Frequency converter NONE
Gross weight 43.4 lb
Housing Cast iron
IE Efficiency class IE3
Immersion depth 10.7 in
Impeller Stainless steel
Impellers 0
Insulation class (IEC 85) F
Liquid temperature range 14 .. 194 °F
Mains frequency 50 Hz
Material code A
Material Pricing Group 32
Max pressure at stated temp 145 psi / 194 °F
Maximum ambient temperature 140 °F
Maximum current consumption 4/2.32 A
Maximum operating pressure 10 bar
Minimum efficiency index, MEI ≥ 0.7
Model A
Motor CE
Motor standard IEC
Multi plug N
Net weight 41.0 lb
Number of reduced-diameter impellers 0
Product family MTH 2
Pump housing Cast iron
Pump version A
Pumped liquid Emulsion
Rated current 3.30/1.90 A
Rated flow 13.2 US gpm
Rated head 152.6 ft
Rated power - P2 0.75 kW
Rated speed 2855 rpm
Rated voltage 3 x 220-240D/380-415Y V
Real Time Delivery date to be confirmed on Sales Order  Update with real time availability and Net price
Selected liquid temperature 68 °F
Service factor 1.3
Size 80A
Size of outlet connection 3/4 inch
Standard IEC
Starting current 580-620 %
Suitable for 50/60 Hz Y
Terminal box position 6
Type of connection Rp
Version A

Motor Curves

Dimensional Drawing

DWiring Diagram
