Description
Grundfos 99553357 - KWM.64.800.18.T.60.1135.M.46 This product is manufactured by Grundfos for various industrial applications. For more information on specifications and applications please chat or call our team.
EAN
5713830935170
Applications
Wastewater
Motor efficiency at full load 1
0.921
Maximum ambient temperature
104 °F
Density
62.29 lb/ft³
Maximum operating pressure
10 bar
Power input P1
651.5 kW
Moisture switch
Y
Rated voltage
3 x 460 V
Moment of inertia
12960 lb ft²
Length of sensor cable
10 m
Maximum current consumption
1110 A
Starting current
6100 A
Mains frequency
60 Hz
Insulation class (IEC 85)
F
Breakdown torque
33200 Nm
Motor efficiency at 1/2 load
0.917
Built-in motor protection
PTO/PT100
Net weight
25200.0 lb
Number of poles
18
Rated speed
390 rpm
Gross weight
27200.0 lb
Rated power - P2
600 kW
Enclosure class (IEC 34-5)
IP68
Motor efficiency at 3/4 load
0.92
Cable type
PNCTR-S
Service factor
1.15
Power cable type
PNCTR-S
Length of power cable
10 m
Number of power cables
3
Max starts per hour
10
Cos phi 1/1
73.7
Approvals
CE
Rated flow
62900 US gpm
Maximum flow
5150 l/s
Minimum flow
2500 l/s
Diameter
44.7 in
Power 1
651.5 kW
Maximum head
44.95 ft
Housing
Cast iron
Cos phi 1/2
60.9
Rated head
38.72 ft
Actual impeller diameter
44.7 in
Type of impeller
Open impeller
Type
PNCTR-S
Cos phi 3/4
70.4
Max. Particle
150 mm
Impeller
DUCTILE IRON
Pump housing
Cast iron
Switch
Y
No. of blades
3
