Description
Grundfos 98183635 - CRNE 32-6 A-G-A-E-HQQE This product is manufactured by Grundfos for various industrial applications. For more information on specifications and applications please chat or call our team.
EAN
5711491088563
Applications
Industrial applications
Material Pricing Group
31
Motor efficiency at full load 1
0.917
IE Efficiency class
NEMA Premium / IE3 60Hz
Code for rubber
E
Maximum ambient temperature
104 °F
Material code
A
Density
62.29 lb/ft³
Max pressure at stated temp
435 psi / 250 °F
Maximum operating pressure
30 bar
Size of inlet connection
2 1/2 inch
Power factor 1
0.88
Support bearing
Graflon
Selected liquid temperature
68 °F
Type of connection
ANSI
Bearing 1
SIC
Bearing 2
Graflon
Rated voltage
3 x 460 V
Flange size for motor
284TC
Pumped liquid
Water
Size of outlet connection
2 1/2 inch
Connect code
G
Liquid temperature range
-40 .. 248 °F
Mains frequency
60 Hz
Insulation class (IEC 85)
F
Built-in motor protection
YES
Net weight
473.0 lb
Number of poles
2
Rated speed
480-3540 rpm
Gross weight
491.0 lb
Rated power - P2
18.5 kW
Enclosure class (IEC 34-5)
IP55
Power (P2) required by pump
18.5 kW
Pressure rating for connection
PN 40
Rated current
30.5 A
Service factor
1.15
Config. file no
95139704
Frequency converter
Built-in
Motor type
160AC
Terminal box position
6
Function Module
ADVANCED I/O
Pressure sensor
N
Pump speed on which pump data are based
3521 rpm
Stages
6
Approvals
CURUS
Rated flow
159 US gpm
Model
B
Version
A
Diameter
4.66 in
Motor
Standard motor size
Rubber
E
Maximum head
553.5 ft
Approvals for drinking water
NSF/ANSI 61
Motor standard
NEMA
DOE Pump Energy Index VL
0.44
Rated head
429.5 ft
Actual impeller diameter
4.66 in
Type
160AC
Curve tolerance
ISO9906:2012 3B
Impellers
0
Connection
PN 40
Impeller
Stainless steel
Code for shaft seal
HQQE
Number of reduced-diameter impellers
0
Flange rating inlet
300 lb
Pump
18.5 kW
Low NPSH
N
Standard
NEMA
Pump version
A
