Grundfos 92771519 - CRNE 20-2 K-FGJ-A-E-HQQE | Vertical | Multistage | Inline | Stainless Steel

GRUNDFOSSKU: 92771519

Contact for price
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Grundfos 92771519 - CRNE 20-2 K-FGJ-A-E-HQQE Vertical Multistage Inline Pump

The Grundfos 92771519 - CRNE 20-2 K-FGJ-A-E-HQQE is a high-performance vertical multistage inline pump designed for a variety of industrial applications. Manufactured by Grundfos, a leader in pump technology, this model is engineered for efficiency and reliability, making it an ideal choice for high-pressure systems.

With its stainless steel construction, the CRNE 20-2 offers excellent durability and corrosion resistance, ensuring a long service life even in demanding environments. This pump is perfect for applications requiring consistent flow and pressure, and it is suitable for both water and other compatible liquids.

At Pump-Stop, we are your preferred source for replacement pumps and parts. If you have questions or need assistance in finding the right pump for your application, please don't hesitate to call us at (781) 281-8905. We recommend checking your current pump for the exact part number or SKU to ensure compatibility. If you’re having trouble locating the right item, our knowledgeable team is here to help!

Explore the reliability and efficiency of the Grundfos CRNE 20-2 K-FGJ-A-E-HQQE and elevate your pumping solutions today!

EAN 5715119375394
Actual impeller diameter 4.13 in
Approvals CURUS
Built-in motor protection ELEC
Code for rubber E
Code for shaft seal HQQE
Config. file no 99074235
Connect code FGJ
Connection PN 25
Control panel Graphical
Curve tolerance ISO9906:2012 3B
Density 62.29 lb/ft³
Diameter 4.13 in
DOE Pump Energy Index VL 0.44
Enclosure class (IEC 34-5) IP55
Flange rating inlet 300 lb
Flange size for motor 213TC
Frequency converter Built-in
Function Module FM300 - Advanced
Gross weight 179.0 lb
IE Efficiency class IE5
Impeller Stainless steel
Impellers 0
Insulation class (IEC 85) F
Liquid temperature range -4 .. 248 °F
Low NPSH Y
Mains frequency 60 Hz
Material code A
Material Pricing Group 31
Max pressure at stated temp 363 psi / 250 °F
Maximum ambient temperature 122 °F
Maximum head 158.1 ft
Maximum operating pressure 25 bar
Model A
Motor 213TC
Motor efficiency at full load 1 0.924
Motor standard NEMA
Motor type 132E
Net weight 161.0 lb
Number of reduced-diameter impellers 0
Power (P2) required by pump 5.5 kW
Power factor 1 0.91-0.89
Pressure rating for connection PN 25
Pressure sensor N
Pump 5.5 kW
Pump speed on which pump data are based 3467 rpm
Pump version K
Pumped liquid Water
Rated current 9.10-8.50 A
Rated flow 111 US gpm
Rated head 128 ft
Rated power - P2 5.5 kW
Rated speed 360-4000 rpm
Rated voltage 3 x 440-480 V
Real Time Delivery date to be confirmed on Sales Order  Update with real time availability and Net price
Rubber E
Selected liquid temperature 68 °F
Service factor 1.15
Size of inlet connection DN 50
Size of outlet connection DN 50
Stages 2
Standard NEMA
Type 132E
Type of connection DIN / ANSI / JIS
Version K

Motor Curves

Dimensional Drawing

DWiring Diagram
