Image shown may not be actual product
Grundfos 97740287 - CRN 64-3-1 H-G44-A-E-HQQE
Grundfos 97740287 - CRN 64-3-1 H-G44-A-E-HQQE
Grundfos 97740287 - CRN 64-3-1 H-G44-A-E-HQQE
Grundfos 97740287 - CRN 64-3-1 H-G44-A-E-HQQE

Grundfos 97740287 - CRN 64-3-1 H-G44-A-E-HQQE

Save $9,908.64
GRUNDFOSSKU: 97740287
Price:
$10,734.36 $20,643.00
Delivery date to be confirmed on Sales Order
Chat or Call for most up to date lead times. (781) 281-8905

Description

CRN 64-3-1 H-G44-A-E-HQQE | CR-H pumps are horizontal end suction pumps typically mounted on baseplates. The end suction design enables the pump to be installed horizontally in traditional, end suction design piping where the pump has an axial suction port and a radial center line discharge port. This design allows “back pull-out” capability. This means the pump usually can be easily serviced without removing the volute from the pipe system. CR-H pumps can be selected that meet ASME B73. 1 dimensional standards for suction and discharge piping as well as many of the baseplate dimensional standards. CR-H pumps do not fully comply with the ASME B73. 1 specification.

Code for rubber E
Material code A
Maximum operating pressure 232.06 psi
Support bearing Graflon
Bearing 1 Graflon
Flange size for motor 324TC
Connect code G44
Liquid temperature range -40 .. 248 °F
Net weight 221.0 lb
Gross weight 382.0 lb
Pressure rating for connection PN 16
Shaft Product name:CRN 64-3-1 H-G44-A-E-HQQE
Frequency converter NONE
Sales region USA
Pressure sensor N
Stages 3
Rated flow 337 US gpm
Model B
Version H
Motor 324TC
Rubber E
Approvals on nameplate CE,NSF/ANSI 61
Maximum head 365.5 ft
Motor standard NEMA
Rated head 283.8 ft
Curve tolerance ISO9906:2012 3B
Impellers 1
Connection PN 16
Impeller Stainless steel
Code for shaft seal HQQE
Number of reduced-diameter impellers 1
Flange rating inlet 150 lb
Pump Y
Low NPSH N
Standard NEMA
Pump version H
