Description
Grundfos 97741902 - CRN 32-3 H-G60-A-E-HQQE This product is manufactured by Grundfos for various industrial applications. For more information on specifications and applications please chat or call our team.
Approvals on nameplate
CE,NSF/ANSI 61
Bearing 1
Graflon
Code for rubber
E
Code for shaft seal
HQQE
Connect code
G60
Connection
PN 16
Curve tolerance
ISO9906:2012 3B
Flange rating inlet
150 lb
Flange size for motor
254TC
Frequency converter
NONE
Gross weight
323.0 lb
Impeller
Stainless steel
Impellers
0
Liquid max temp
248°F
Liquid temperature range
-40 .. 248 °F
Low NPSH
N
Material code
A
Maximum head
269 ft
Maximum operating pressure
232.06 psi
Model
B
Motor
254TC
Motor standard
NEMA
n rpm
3444rpm
Net weight
162.0 lb
Number of reduced-diameter impellers
0
Pressure rating for connection
PN 16
Pressure sensor
N
Pump
Y
Pump version
H
Rated flow
132 US gpm
Rated head
221.5 ft
Rubber
E
Sales region
USA
Shaft
Product name:CRN 32-3 H-G60-A-E-HQQE
Shaft seal
HQQE
Stages
3
Standard
NEMA
Support bearing
Graflon
Version
H
Motor Curves
