Description
Grundfos 92542746 - CRN 255-4-2 A-G-A-V-HQQV This product is manufactured by Grundfos for various industrial applications. For more information on specifications and applications please chat or call our team.
Code for rubber
V
Material code
A
Maximum operating pressure
580.15 psi
Support bearing
Graflon
Type of connection
ANSI
Bearing 1
Graflon
Flange size for motor
449TSD
Connect code
G
Liquid temperature range
-4 .. 194 °F
Net weight
816.0 lb
Gross weight
1070.0 lb
Power (P2) required by pump
300 HP
Pressure rating for connection
300 lb
Shaft
Product name:CRN 255-4-2 A-G-A-V-HQQV
Frequency converter
NONE
Stages
4
Rated flow
1350 US gpm
Model
A
Version
A
Motor
449TSD
Rubber
V
Maximum head
859.3 ft
Approvals for drinking water
NSF/ANSI 372
Motor standard
NEMA
Material certified according to
European standards
Thrust handling device
Y
Rated head
650 ft
Curve tolerance
ISO9906:2012 3B
Impellers
2
Connection
300 lb
Impeller
Stainless steel
Code for shaft seal
HQQV
Number of reduced-diameter impellers
2
Pump
300 HP
Low NPSH
N
Standard
NEMA
Pump version
A
