Description
Grundfos 99400507 - CRN 215-2-2 A-G-A-E-HQQE This product is manufactured by Grundfos for various industrial applications. For more information on specifications and applications please chat or call our team.
EAN
5713828501554
Applications
Industrial applications
Material Pricing Group
33
Code for rubber
E
Material code
A
Density
62.29 lb/ft³
Max pressure at stated temp
232 psi / 250 °F
Maximum operating pressure
232.06 psi
Support bearing
Graflon
Selected liquid temperature
68 °F
Type of connection
ANSI
Bearing 1
WC/WC
Pressure rating
150 lb
Flange size for motor
405TSD
Pumped liquid
Water
Pump outlet
8
Pump inlet
8
Connect code
G
Liquid temperature range
-4 .. 248 °F
Net weight
611.0 lb
Gross weight
867.0 lb
Power (P2) required by pump
100 HP
Pressure rating for connection
150 lb
Frequency converter
NONE
Stages
2
Rated flow
1140 US gpm
Flange standard
ANSI
Model
A
Version
A
Motor
405TSD
Rubber
E
Maximum head
394.4 ft
Approvals for drinking water
NSF/ANSI 61,NSF/ANSI 372
Motor standard
NEMA
Material certified according to
European standards
Thrust handling device
SiC/WC
Rated head
263.1 ft
Curve tolerance
ISO9906:2012 3B
Impellers
2
Connection
ANSI
Impeller
Stainless steel
Code for shaft seal
HQQE
Pump housing
Stainless steel
Number of reduced-diameter impellers
2
Pump
100 HP
Low NPSH
N
Standard
NEMA
Pump version
A
Motor Curves
