EAN
        5712607598815















        Applications
        Industrial applications










            Approvals for drinking water

              NSF/ANSI 372








            Bearing 1

              WC/WC








            Built-in motor protection

              NONE








            Code for rubber

              V








            Code for shaft seal

              HQQV








            Connect code

              P








            Connection

              PJE








            Connection 2

              800 psi








            Cooling

              IC 411








            Curve tolerance

              ISO9906:2012 3B








            Density

              62.29 lb/ft³














            Enclosure class (IEC 34-5)

              IP55








            Eta 1/1

              0.93








            Flange size for motor

              326TSC








            Frequency

              60 HZ








            Frequency converter

              NONE








            Full load SF current

              140/70.1 A








            Gross weight




              1450.0 lb








            IE Eff. Class

              IE3 / NEMA Premium








            IE efficiency

              IE3 93%








            IE Efficiency class

              IE3 / NEMA Premium








            Impeller

              Stainless steel








            Impellers

              1








            Insulation

              F








            Insulation class (IEC 85)

              F










            Liquid max temp

              90°C








            Liquid temperature range

              -4 .. 194 °F








            Low NPSH

              N








            Material certified according to

              European standards








            Material code

              A








            Material Pricing Group

              33








            Max pressure at stated temp

              363 psi / 194 °F








            Maximum ambient temperature

              104 °F








            Maximum head

              193.3 ft








            Maximum operating pressure

              362.59 psi








            Maximum permissible operating pressure

              25bar








            Model

              A








            Motor

              326TSC










            Motor efficiency at 1/2 load

              0.93








            Motor efficiency at 3/4 load

              0.93








            Motor efficiency at full load 1

              0.93








            Motor protec

              NONE








            Motor standard

              NEMA








            Motor type

              WEG








            n rpm

              3550rpm








            Net weight




              1090.0 lb








            Number of poles

              2








            Number of reduced-diameter impellers

              1








            P2 HP

              50 HP








            P2 kW

              37kW








            Phase

              3








            Power (P2) required by pump

              50 HP








            Power factor 1

              0.89








            Pressure rating

              800 psi








            Pressure rating for connection

              800 psi








            Product family

              CRN 215








            Pump

              50 HP








            Pump housing

              Stainless steel








            Pump inlet

              8








            Pump outlet

              8








            Pump version

              A








            Pumped liquid

              Water








            Rated current

              112/56.1 A








            Rated flow

              1140 US gpm








            Rated flow 2

              1140 US gpm








            Rated head

              131.9 ft








            Rated head 2

              131.9 ft








            Rated power - P2

              50 HP








            Rated speed

              3550 rpm








            Rated voltage

              3 x 230/460 V








            Real Time

              Delivery date to be confirmed on Sales Order Update with real time availability and Net price








            Rubber

              V








            Selected liquid temperature

              68 °F








            Service factor

              1.25








            Shaft seal

              HQQV








            Stages

              1








            Standard

              NEMA








            Starting current

              6.2








            Support bearing

              Graflon








            Thrust handling device

              N








            Type

              WEG








            Type of connection

              PJE








            Version

              A
