Grundfos 99473533 - CRN 20-4 M-FGJ-L-E | Multistage | Centrifugal | Vertical | Inline

GRUNDFOSSKU: 99473533

Contact for price
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

CRN 20-4 M-FGJ-L-E | Vertical, multistage centrifugal pump with inlet and outlet ports on same the level (inline). Pump materials in contact with the liquid are in high-grade stainless steel. Pipe connection is via combined DIN-ANSI-JIS flanges.

EAN 5713829692343
Approvals EAC
Code for rubber E
Connect code FGJ
Connection PN 25
Curve tolerance ISO9906:2012 3B
Density 62.29 lb/ft³
Flange rating inlet 300 lb
Flange size for motor FF265
Frequency converter NONE
Gross weight 256.0 lb
Impeller Stainless steel
Impellers 0
Liquid temperature range -4 .. 248 °F
Low NPSH N
Material code L
Material Pricing Group 6
Max pressure at stated temp 363 psi / 250 °F
Maximum head 192.9 ft
Maximum operating pressure 25 bar
Minimum efficiency index, MEI ≥ 0.7
Model A
Motor FF265
Motor No 99472705
Motor standard IEC
Net weight 207.0 lb
Number of reduced-diameter impellers 0
Power (P2) required by pump 5.5 kW
Pressure rating for connection PN 25
Pressure sensor N
Pump 5.5 kW
Pump speed on which pump data are based 2919 rpm
Pump version M
Pumped liquid Water
Rated flow 92.5 US gpm
Rated head 153.2 ft
Real Time Delivery date to be confirmed on Sales Order  Update with real time availability and Net price
Rubber E
Selected liquid temperature 68 °F
Size of inlet connection DN 50
Size of outlet connection DN 50
Stages 4
Standard IEC
Type of connection DIN / ANSI / JIS
Version M

Motor Curves

Dimensional Drawing
