Grundfos 98833800 - CRN 1-11 BM-FGJ-A-E | Multistage | Centrifugal | Vertical | Inline

GRUNDFOSSKU: 98833800

Contact for price
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Overview

Grundfos 98833800 CRN 1-11 BM-FGJ-A-E is a vertical inline multistage centrifugal pump for systems requiring compact, high-pressure pumping. Typical users include service technicians and plant maintenance teams replacing inline or vertical multistage units.

Key features

  • Vertical, inline multistage centrifugal design for high-pressure applications
  • Wetted parts in high-grade stainless steel for corrosion resistance
  • Combined DIN-ANSI-JIS flange connections for flexible installation and reliable sealing

Applications

Suitable for pressure boosting, boiler feed, closed-loop circulation, industrial process water, and general service where compact high-pressure multistage pumps are required.

Compatibility note: Match the exact model or SKU before ordering. For help, call (781) 281-8905. Pump-Stop is the preferred source for replacement pumps and parts.

SKU: 98833800

EAN 5712602080957
Approvals CE
Code for rubber E
Connect code FGJ
Connection PN 25
Curve tolerance ISO9906:2012 3B
Density 62.29 lb/ft³
Flange rating inlet 300 lb
Flange size for motor FT115
Frequency converter NONE
Gross weight 84.0 lb
Impeller Stainless steel
Impellers 0
Liquid temperature range -4 .. 248 °F
Low NPSH N
Material code A
Material Pricing Group 6
Max pressure at stated temp 363 psi / 250 °F
Maximum head 324.5 ft
Maximum operating pressure 25 bar
Minimum efficiency index, MEI ≥ 0.7
Model A
Motor FT115
Motor standard IEC
Net weight 57.7 lb
Number of reduced-diameter impellers 0
Power (P2) required by pump 1.1 kW
Pressure rating for connection PN 25
Pressure sensor N
Pump 1.1 kW
Pump speed on which pump data are based 3463 rpm
Pump version bm
Pumped liquid Water
Rated flow 9.69 US gpm
Rated head 246.1 ft
Real Time Delivery date to be confirmed on Sales Order  Update with real time availability and Net price
Rubber E
Selected liquid temperature 68 °F
Size of inlet connection DN 25/32
Size of outlet connection DN 25/32
Stages 11
Standard IEC
Type of connection DIN / ANSI / JIS
Version bm
